English
3
1 Garden hose connector (female)
2 Water inlet with connector
3 ON/OFF switch
4 High pressure hose
5 Dosage regulator for detergent
6 Storage for trigger gun
7 High-pressure hose drum
8 Transport handle
9 Hand crank for hose drum
10 Screws (Philips style)
11 Hose retention clip
12 Holder bracket
13 Detergent suction tube with filter
and cap
14 Detergent tank
15 Accessory storage
16 Storage hook for mains connection
cable
17 Power cord with Ground Fault Cir-
cuit Interrupter (GFCI)
18 Wheels
19 Trigger gun
20 Lock trigger gun
21 Key to detach the high pressure
hose from the trigger gun
22 Dirtblaster ® (Rotary spray wand)
23 Vario Power Spray wand
MODEL OVERVIEW
