24
PARTS LIST
MODEL NO.: CH2730SQB CH2736SQB
CH2742SQB CH2748SQB
(Optional Duct Cover)
NO. DESCRIPTION MODEL /SIZE PART NO.
1 Multi Duct Exhaust C1-0507-1530
2 Vent Cover (Top) B101-1530-12
3 Vent Cover (Rear) C1-0508-1530-A
4 Vent Cover Frame C1-0508-1530-B
5 Hood Casing CH2730SQB 10-4930B-51
CH2736SQB 10-4936B-51
CH2742SQB 10-4942B-51
CH2748SQB 10-4948B-51
6 Halogen Light (12V 20W Max.) C1-0403-0101
7 Control Unit C1-0501-0101
8 Control Board C1-0404-4001-A
9 Transformer Support C1-0201-1530
10 Transformer (Motor) CH2730SQB C1-0402-0120-40
CH2736SQB C1-0402-0120-40
CH2742SQB C1-0402-0120-60
CH2748SQB C1-0402-0120-60
11
A
B
A
B
Air Chamber
Air Chamber (Top)
CH2730SQB C1-0101-1530
Air Chamber (Side) CH2736SQB C1-0102-1530
Air Chamber (Top) CH2742SQB C1-0101-1542
Air Chamber (Side) CH2748SQB C1-0102-1542
12 Transformer (Light) C1-0402-A120-01
13 Capacitor C1-0401-0120-01
14 Processor Board Box C1-0501-0102
15 Processor Board C1-0404-4110-B
16 Round Head Screw (1/8” x 3/8”) C1-0708-0003
17 Motor Position Screw (TS 1/4 x 7/16 C1-0703-0001
18 Motor (Right) C1-0301-0120-23B
19 Motor (Left) C1-0301-0120-23A
20 Turbine Impeller ( Right) C1-0251-0880-B
21 Turbine Impeller ( Left) C1-0251-0880-A
22 Oil Tunnel Seal C1-0502-0301
23 Oil Tunnel C1-0502-0102
24 Impeller Plastic Cover C1-0251-0001
25 Safety Screen C1-0602-0101
26 Safety Screen Screw C1-0705-0001
27 Baffle filter B101-4930-09
28 Bottom Casing B101-4930-09
NO. DESCRIPTION MODEL /SIZE PART NO.
01 Hood-Mounting Bracket C1-0221-1530
02 Screws (TS 4 x 8 mm) C1-0708-0006
03 Duct Cover CH1120DC 12-15300-51
04 Duct Cover-Mounting Bracket C1-0221-1530
05 Screw (3/16” x 3/8”) C1-0707-0001
06 Rubber Stand C1-0511-0382
07 Screw ( TS 4 x 8 mm) C1-0708-0006
