DOME INSTALLATION AND EXTERNAL WIRING
Fig. 7
IMPORTANT! USE ONLY THE COAXIAL CABLES SUPPLIED WITH THE SEA-KING.
DO NOT CUT COAX. COIL AND STORE EXCESS CABLE IN THE CABINET
WITH THE COMPONENTS.
If coaxial cable other than that supplied with the Sea-King is used, the
following guide lines must be followed:
1) Ends must be terminated with SNAP-N-SEAL ® connectors or
F-compression style connectors as shown in Fig. 7. (DO NOT USE
TWIST-ON CONNECTORS.)
2) Cable must be RG6 or better, and rated at 2.2 GHz or higher.
IMPORTANT!
COMPRESSION STYLE CRIMPER ONLY!
(Do not use hex style.)
IMPORTANT!
Use factory
recommended stripper
only.
IMPORTANT!
Rubber O-rings must be
REMOVED from ends of all
SNAP-N-SEAL ® connectors
and F-compression style
connectors.
Page 9
