SoloX Subwoofer
Moun
ting
Mounting
Now that you have opened the box and read “The
Adventures of Sam Stikman” and decided on which enclosure
design to use, you may now remove the SoloX from it’s box.
Please follow the instructions
lined out here to insure proper
installation.
1. With assistance from a
friend remove the SoloX from
the cardboard facilitation cham-
ber.
2. Once out of the carton remove
the (4) four acorn head nuts and
(8) eight bolts securing the SPAIR
to the BAM and wood baffle
assembly. Place SPAIR in safe
clean location!
ATTENTION!
3. Install the Gap Cap into the
BAM around the pole-piece to
protect the motor assembly
from debris while you are
installing the woofer. If any
metal shavings were to fall into
the gap, they would be impossi-
ble to remove! Please use the
Gap Cap!
4. With the Gap Cap now
installed remove the (4) double
end threaded studs that lock the
BAM to the wood baffle assem-
bly.
The SPLAT and wood baffle will
now come free from the BAM.
The baffle will now become your
mounting template.
5. Place the wood template on
your enclosure baffle to mark
the holes for mounting.
