Kenwood USA Corporation

July-07

MODEL

DESCRIPTION

LIST

TK-190K

VHF Low Band 29.7 – 37.0 MHz 6W, 16 Channels

642.00

TK-190K2

VHF Low Band 35.0 – 50.0 MHz 6W, 16 Channels

642.00

Important Notice

Regarding the TK-190 Model Radios!

*** If this transceiver is programmed for more than one channel, the transmit

frequencies must be within a 500 kHz range.***

- The physical condition of the antenna may affect the radio's performance.

- If the original KRA-21 antenna is worn, bent or damaged, immediately have your
Kenwood authorized dealer replace the antenna with a new, properly adjusted KRA-21
antenna.

- Failure to follow these instructions may cause poor performance, damage to your
transceiver, and may also place excess transmitter energy on the metal portions of your
radio, which could make the transceiver uncomfortable to handle when transmitting.

- When transmitting, if your hand feels uncomfortable, contact your Kenwood dealer for
a transceiver inspection, and possible antenna replacement.

ANTENNAS

KRA-21

1

Tunable VHF Low Band helical antenna 29.7-50MHz. (Note: Antenna band width is 1
MHz.)

40.00

BATTERIES AND CHARGERS

KNB-17A

1500 mAh, 7.2 VDC (4/5W), NiCd battery

67.00

KNB-17BK

2

Intrinsically Safe Battery 1500 mAH, 7.2 VDC (4/5W), NiCd battery
[Intrinsically Safe Option] - must order L-835.

100.00

KNB-21N

7

1600 mAh NiMH (more than 10 hours life @ 5-5-90) - requires KSC-24 charger. Note:
Not compatible with Kenwood NiCd chargers or earlier model leather cases.

60.00

KNB-22N

7

2100 mAh NiMH (more than 13 hours life @ 5-5-90) - requires KSC-24 charger. Note:
Not compatible with Kenwood NiCd chargers or earlier model leather cases.

70.00

KNB-22NC

7,8

2100 mAh NiMH battery - requires KSC-24 charger - [Intrinsically Safe Option] - must
order L-979.

117.00

KBP-4

3

AA Alkaline Refillable Battery Pack for TK-190/290/390/280/380 (12 AA Alkaline 9V)
Battery cells not incl.

41.00

Land Mobile Radio Division

Price Guide

Heavy-duty Spring-action Belt Clip, Channel Selector Mechanical stop and dressing plate included -

Antenna & Battery not included.

• MIL-STD 810 C/D/E
• Internal Noise-Canceling Microphone
• Operator Selectable Tone/Code (OST)
• Recessed Emergency / Function Key
• Companded Audio
• "Programmable" MIL-SPEC Speak Mics

• 16 Channel Capacity
• Wide-Band Coverage
• 7-Character Invert Display
• Priority Scan
• Programable Power Per Channel
• 5 Programmable Keys

TK-190

Low Band Portable Radio

Page 1 of 4
