OVEN PARTS
2
For Models:KBMC147HBL05,KBMC147HWH05, KBMC147HBT05,KBMC147HSS05
(BLACK) (WHITE) (BISCUIT) (STAINLESS)
8186469
Illus. Part
No. No. DESCRIPTION
1
Literature Parts
4452615 Installation
Instructions
8304067 Use & Care Guide
4450786 Cook Guide Label
4451052 Guide−Easy Use M/W
8303854 Tech Sheet
4449264 Easy Set Guide
3191638 Safer Cooking Tips
9759133 Safer Cooking Tips
2
Trim, Side
4452624 RH Black
4452626 RH White
4452971 RH Biscuit
4452556 RH Stainless
4452625 LH Black
4452627 LH White
4452972 LH Biscuit
4452557 LH Stainless
3
4451605 Cap, Spacer
4
Rail, Side
4456545 Right Side
4456546 Left Side
5
4452559 Side, Chassis
(R.H. & L.H.)
4455475 Screw
6
4456400 Base, Chassis
7
Trim, Bottom
4456539 Black
4456541 White
4456543 Biscuit
4456537 Stainless
8
4452553 Chassis, Back
9
4455471 Spacer
10
3400832 Screw
11
4449809 Screw
12
4452492 Insulation−Grill
13
4452491 Insulation−Top
