Kobe Range Hoods RA3830SQ - Manual (Page 16)

14
SPECIFICATIONS
MODEL / SIZE RA3830SQ / 30”
RA3836SQ / 36”
COLOR # 430 Commercial Grade Stainless Steel
VOLTAGE 120V 60Hz
NUMBER OF MOTORS 2
DESIGN 18-Gauge Seamless
FAN TYPE Twin Turbine Impeller
EXHAUST 6” Round
CONTROLS Three Speed (QuietMode, Low, & High)
HALOGEN LIGHTS 12V 20W x 2
HOOD DIMENSION
(W x D x H)
(RA3830SQ) 29-3/4” x 20-1/2” x 5-1/8”
(RA3836SQ) 35-1/4” x 20-1/2” x 5-1/8”
OPTIONAL ACCESSORIES
(W x D x H)
1) Two-Piece Adjustable Duct Cover
(RA1020DC) 10-5/8” x 9-1/8” x (20-5/8” ~ 39-5/8”)
2) 30” Stainless Steel Back Panel
(SSP30) 30” x 1/10” x 32”
3) 36” Stainless Steel Back Panel
(SSP36) 36” x 1/10” x 32”
Net Gross
(RA3830SQ) 37.0 43.0 WEIGHT (lbs)
(RA3836SQ) 39.0 47.0
SPEED QuietMode Low High
Air Capacity (cfm)* 330 480 720
Sone 1.0* 2.8 4.8
*In House Test Static Pressure “0”. One sone is equivalent to the sound of a refrigerator at 40 decibels.
**Specifications information is subject to change without notice.
