Oven parts – KITCHENAID KGSK901SWH02 User Manual
Page 4
OVEN PARTS
4
For Models: KGSK901SBL02, KGSK901SWH02, KGSK901SSS02
(Black) (White) (Stainless)
W10269050
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
Trim, Side
Right
W10109540 Black
W10109570 White
W10140548 Stainless
Left
W10109490 Black
W10109520 White
W10140547 Stainless
2
8053971 Brace, Main Back
3
Hinge Receiver
4455606 Right
4455605 Left
4 W10105790 Bumper, Door
5
4448444 Grommet
6
3400832 Screw
7
8303099 Top Chassis
8
9759722 Insulation, Body
Side Trim
9
9761666 Tube, Vent
10 W10067870 Lens, Light
11 W10009930 Assembly, Oven
Light
12
4452166 Bulb, Light
13
9757732 Shield, Heat
14 W10115831 Frame, Front
15 W10074200 Gasket, Door
16
9757070 Plate, Relectance
17
4452152 Bracket, Mounting
18
9757685 Guide, Side Panel
19
9757461 Bracket,Side Panel
20
Oven, Side Panel
9760723PB Black
9760723PW White
21
9757811 Brace, Side Panel
22 W10195934 Latch, Motorized
23
9757807 Thermostat
24
9759890 Clip, Side Panel
25
4455641 Side, Chassis
26
9759762 Back, Chassis
27
Liner, Oven
(Not serviceable)
28
9759945 Standoff, Rear
29 W10131825 Sensor
30
9756454 Bracket, GOC
31
9760223 Slide, DSI
32 W10083460 Slide, GOC
33
9762774 Central, Appliance
34
3196537 Screw
35
9760481 Washer, Insulation
Body Side Trim
37
9759242 Thermostat (TOD)
38
4449743 Screw
39 W10110534 Base, Chassis
40
4448933 Retainer, Gasket
41
9758583 Cover, Back
42
4449809 Screw
43
Vent, Bottom Upper
9756481BL Black
9756481WH White
9756481SS Stainless
44
Trim, Lower Vent
W10153486 Black
W10153488 White
W10154789 Stainless
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
9756817 Insulation, Wrap
W10095410 Insulation, Cover
Back, Top
W10095400 Insulation, Cover
Back, Side
9756470 Insulation, Back
