Assembly
The Triumph 7.3t Treadmill will require assembly before operating. After opening the box, remove any
packing material from the treadmill.
Do not throw away any packing materials until the unit is working properly.
Place the base on a clean, level surface. Make sure the electrical cord will easily reach an electrical outlet.
Locate the hardware pack and identify the following parts required for assembly.
Tools:
1. Allen Wrench- 3/16”
2. Allen Wrench- 7/32”
3. Philip Screwdriver
Main Components:
1. Owner’s Manual
2. Console Assembly
3. Left and Right Uprights
4. Left and Right Fender
5. Left and Right Bottom Handle Cover
6. Handle End Caps
7. Deck Assembly
8. Long Bumpers
Hardware:
1. Washer 9*16*1.6 mm (Qty. 12)
2. Spring Washer 8 mm (Qty. 12)
3. Allen Bolt 5/16”-18 x 70 (Qty. 4)
4. Allen Bolt 5/16”-18 x 15 (Qty. 6)
5. Allen Bolt M8*30 (Qty. 2)
6. Shoulder Allen Bolt 5/16”-18 x 45 (Qty. 2)
7. Philip Screw ST4.2*16 (Qty. 8)
Wire Connections:
1. Console Harness
2. EKG Harness
