Parts List
19
REF# KEYS PART# DESCRIPTION QTY.
1 23-0163 UPRIGHT ASSEMBLY 1
2 23-0123 DECK ASSEMBLY 1
3 23-0003 REAR ELEVATION ASSEMBLY 1
4 19-0010 UPRIGHT PIVOT BRACKET 2
5 19-0032 SPRING ANCHOR BRACKET 2
6 19-0019 BELT GUIDES 2
7 19-0015 MOTOR COVER BRACKET 7
8 10-0028 BOARD ISOLATOR 8
9 24-0218 FRONT ROLLER 1
10 09-0013 REAR ROLLER 1
11 04-0025 WALK BELT 1
12 19-0013 FOOT LOCKING MECHANISM LATCH 1
13 12-0044 MOTOR 1
14 12-0022 ACTUATOR 1
15 20-0003 ACTUATOR EXTENSION 1
16 08-0051 MOTOR CONTROLLER 1
17 04-0017 POLY V-BELT 1
18 06-0008 REAR END CAP 1
19 06-0018 MOTOR BASE 1
20 06-0019 CENTER BASE 1
21 06-0020 END BASE 1
22 02-0002A DECK LIFT SPRING 2
23 06-0027 PIVOT COVER 2
24 06-0105 MOTOR COVER 1
25 10-0020 GRIP 2
26 08-0027 REMOTE TOGGLE 2
27 24-0273 CONSOLE ASSEMBLY 1
28 05-0036 EXTRUSION 2
29 03-0011 WALK BOARD 1
30 06-0029 WHEEL SPACER 4
Alliance A4t Treadmill
