Parts list – Keys Fitness CARDIOZONE E-CZ100 User Manual
Page 21
21
Ref #
Part #
Description
Qty
Ref #
Part #
Description
Qty
018D 302-00098
FLAT WASHER 16*20-0.3MM
4
2JPY
306-00723
COLLAR, AEROS
2
0J6C 302-00101
FLAT WASHER 10*20-2MM
10
2HK7 306-00726
END CAP, CONSOLE TUBE AEROS
2
0J4P
302-00102
FLAT WASHER 8*16-1.4MM
8
2GSJ 306-00727
HAND PULSE W/GRIP, AEROS
2
21MY 302-00106
FLAT WASHER 29*24*0.3MM
4
2GSJ 306-00727
HAND PULSE W/GRIP, AEROS
2
0JED 302-00108
C-RING A-16
4
2JPS
306-00728
SLEEVE, PEDAL ARM AEROS
2
0JEG 302-00109
C-RING A-20
1
2GQR 306-00729
FOAM GRIP, AEROS
2
0JEH 302-00110
C-RING A-24
2
2NSW 306-00982
SIDE CASE SUPPORT PLATE, E-CZ100
2
0K94 302-00115
CR. RE. TRUSS HD. TAPPING SCREW M5*12-16
8
2K47 306-00983
STRAIN RELIEF, E-CZ100
1
0K37 302-00118
CR.RE. PAN HD. SCREW & WASHER M5*0.8-16m
7
2NSZ 306-00984
END CAP(RIGHT), E-CZ100
1
0JUX 302-00125
HEX. SOC. HD. CAP BOLT M8*1.25-30MM
4
2NT0 306-00985
END CAP LEFT, E-CZ100
1
0JV2
302-00127
HEX. SOC. HD. CAP BOLT M8*1.25-60MM
2
2HM5 306-00986
FAN, E-CZ100
1
0KQY 302-00135
LOCK NUT M8*1.25 T=8MM, 600E,A7E,EVO-1
6
20TY 306-00987
END CAP, E-CZ100
1
0KRK 302-00144
U-TYPE NUT M5-12MM
8
2NSQ 306-00989
BOOKSTAND, E-CZ100
2
0K2W 302-01131
BOLT M5*12
3
2HRM 306-00990
FAN PROTECTOR, E-CZ100
1
22QV 302-01277
HEX. SOC. TRUSS HD. SCREW M10*1.5-20
2
2KC3 307-00721
CHEST STRAP, CG1-HR
1
0KR0 302-01285
LOCKING NUT, M12*1.75 T12
2
2K84 307-00728
D.C. MOTOR ASSY, ADVENTURE
1
0KQZ 302-01286
LOCKING NUT, M10*1.5 T10
2
2HRN 307-00733
TOP ELECTRON PANEL, E-CZ100
1
0KNM 302-01287
HEX. NUT, M10X1.5 CT=8
6
2GTX 307-00734
CONSOLE CONTROLLER CIRCUIT BOARD, E-C100
1
0K4R 302-01291
CR.-RE. TRUSS HD. SCREW M5*0.8-12
4
2GTY 307-00735
TELEMETRY HR BOARD, E-CZ100
1
0K3X 302-01292
CR.RE. PAN HD. SCREW & WASHER M5*0.8-14
2
28VS 310-00119
WATER BOTTLE
1
0K2C 302-01293
HEX.SOCKET HD.CAP SCREWS M8X1.25-16
4
01H5 310-00172
MAGNET SEAT W/MAGNET, EVO-1
1
0JEJ
302-01296
C-RING A-25
2
27S2 310-00202
ADJUSTABLE FOOT, AEROS
6
21A7 302-01300
RETAINGING RING, CENTER-G
1
21HN 310-00203
BRAKE LEAD, EVO-1/AEROS
1
21X8 302-01304
SPACER, CENTER-G/ACHIEVER/CDT
3
2GQN 311-00040
EDDY CURRENT BRAKE,EVO-1/600E/A7E
1
2HDU 302-01343
M5*0.8-8, CRE.RE. TRUSS, HEAD SCREW
12
2DEV 311-00041
POLY V-BELT PULLEY ASSEMBLY
1
0KNX 302-01350
HEX NUT, 3/8*24
2
2DBE 311-00070
POLY V-BELT PULLEY, EVO-1
1
0J9U 302-01351
SPRING WASHER, 3/8" BLACK
2
2JPZ
311-00091
IDLER WHEEL ASSY, AEROS (WITH PARTS)
1
2K28 302-01377
SCREW, M5X0.8-25 ZINC HRC40~45
8
2JVM 311-00092
IDLER WHEEL, AEROS
1
0K4S 302-01381
SCREW, M5*0.8-16 CR.-RE. TRUSS HD
22
2JVE
313-00380
WIRE HARNESS, MAIN 900MM AEROS
1
2DUD 302-01382
SCREW, M5X0.8-12 CR.-RE. TRUSS HD ZINC
8
2JVD 313-00381
WIRE, HARNESS MAIN 650MM AEROS
1
2JWV 302-01384
BOLT, HEX. SOC. HD. ZINC M10X1.5-95
2
2JWC 313-00382
HARNESS, HAND PULSE HANDLEBAR 700MM
2
2K27 302-01385
BOLT, HEX SOC. HD. CAP ZINC M10X1.5-65
2
2K0W 313-00432
POWER SOURCE SOCKET, E-CZ100
1
2K27 302-01385
BOLT, HEX SOC. HD. CAP ZINC M10X1.5-65
2
2K0X 313-00433
REED SWITCH, E-CZ100
1
0U6V 302-01386
WASHER, FLAT 10X25-3
2
2NUM 313-00434
WIRE HARNESS MAIN, ECZ100
1
2DUE 302-01387
SCREW, CR.- RE. TRUSS HD. ZINC M5X0.8-16
3
2NUL 313-00435
WIRE HARNESS MAIN, E-CZ100
1
2K22 302-01388
SCREW, HEX. SOC TRUSS HD ZINC N8X1.25-16
2
01FD 314-00001
LEFT STICKER 600E
1
0J8N 302-01395
WASHER, FLAT 5/16X7/8-5/64
2
01FE 314-00002
RIGHT STICKER 600E
1
2JUY
302-01396
BOLT, CLAMP AEROS
1
2NRK 314-00134
OVERLAY, E-CZ100, E-CZ200, E-CZ3
1
0JE1
302-01397
C-RING B-42
4
2NRR 314-00135
Decal, Resistance Toggle Sticker, E-CZ10
1
0JP7
302-01398
BOLT, HEX HD M10X1.5-105
2
2NRL 314-00136
Decal, Body Composition Sticker, E-CZ100
1
22LR 302-01401
C-RING, A-16 T=1.2 BLACK
1
2NRM 314-00137
Decal, Program Center Sticker, E-CZ100/E
1
0KR5 302-01402
NUT CHUCK
5
2NRN 314-00138
Decal, Shroud Sticker Right, E-CZ100
1
0K84 302-01585
CR. RE. COUNT HD TAPPING SCREW
3
2NRP 314-00139
Decal, Shroud Sticker Left, E-CZ100
1
0KA9 302-01586
CR.RE. PAN HD. TAPPING SCREW, E-CZ100
2
2NRZ 314-00154
Decal, CZ Chrome Sticker, E-CZ100
2
2LLN 302-01587
HEX. SOC. TRUSS HD. SCREW
4
2JME 319-00262
PLATE, IRON LEFT AEROS
1
2LKX 302-01588
CENTER SHAFT WASHER, E-CZ100
2
2JMC 319-00263
PLATE, IRON RIGHT AEROS
1
0KB9 302-01589
CR.RE. PAN HD. TAPPING SCREW, E-CZ100
1
2JMD 319-00264
PLATE, IRON MIDDLE AEROS
1
2JWX 304-00024
BELT, V-RIBBED 580J5
1
2JPV
319-00266
CRANK ARM, AEROS
2
2HQM 305-00192
COVER SIDE, LEFT UPPER AEROS
1
2JR9 319-00358
RAIL ASSY, AEROS
1
2HQN 305-00193
COVER SIDE, RIGHT UPPER AEROS
1
2JML 319-00360
BRACKET, WHEEL AEROS
2
2GTM 305-00236
TOP CONSOLE PANEL, E-CZ100
1
2JWD 319-00362
PARALLEL KEY, 8X12
2
2GTN 305-00237
BOTTOM CONSOLE PANEL, E-CZ100
1
2JYG 323-00464
PIVOT ARM ASSY, RIGHT AEROS (WITH PARTS)
1
2EXA 306-00275
COVER, CONSOLE TUBE AEROS
1
2JSC 323-00465
PIVOT ARM, AEROS (ARM ONLY)
1
2JM0 306-00276
END CAP, AEROS
2
2NSY 323-00601
SIDE COVER (L.B), E-CZ100
1
0157 306-00282
TRACK WHEEL ASSEMBLY, EVO-1, A7E, AEROS
2
2NSX 323-00602
SIDE COVER (R.B)
1
016C 306-00285
END CAP, 25.2MMX75.2 RECTANGULAR A7E,600
3
2NG3 328-00085
AXLE SEAT, E-CZ100
1
2D3G 306-00622
PEDALS, EVO-1, CENTER-G/ACHIEVER/CDT
2
2NFW 328-00086
AXLE SEAT, E-CZ100
1
2AX2 306-00668
TRANSPORTATION WHEEL, CENTER-G
2
2NTN 328-00087
FOAM, E-CZ100
2
2J90
306-00719
COVER, BOTTOM PLATE AEROS
1
2JM3 330-00094
CENTER SHAFT, AEROS
1
2HQP 306-00720
COVER, UPPER PLATE AEROS
1
0HVP 331-00036
BALL BEARING 6004ZZ ( 600E)
4
2HPP 306-00721
SIDE CASE SUPPORT PLATE, LEFT AEROS
1
2KX7 331-00105
BALL BEARING, 6203ZZ
2
2HQJ 306-00722
SIDE CASE SUPPORT PLATE, RIGHT AEROS
1
2KX8 331-00106
BALL BEARING, 6204ZZ
2
2KX9 331-00107
BALL BEARING, 6005ZZ
2
E-CZ100 Elliptical Parts List Rev A.
Parts List
