Page 13

RPD-1151/1158 User Manual
10
1.4 Mounting the unit to your cabinet
The unit is designed for standard 750mm and 900mm cabinets*. You may find the
rear mounting kit in the carton.
Please use the following combination to fit in different cabinets.
For 750mm cabinets
Short L-bracket x 2
Extended bracket x 2
Supporting bracket x 2
For 900mm cabinets
Long L-bracket x 2
Extended bracket x 2
Supporting bracket x 2
