Keys Fitness ET835D - Manual (Page 10)

17
835 Display Instructions
BUTTON FUNCTIONS
MODE Press to select between functions: TIME,
DISTANCE, CALORIES, and PULSE for
target presetting.
SET Press to preset the target values of TIME,
DISTANCE, CALORIES, and PULSE.
RESET Press to reset a function window to zero. To clear
out the readings in all of the console windows, you
must press and hold the Reset button for 3 seconds.
NO. PART QTY
64 M8X15mm SCREW 6
65 M10X55-8mm SCREW 2
66 M10X48mm SCREW 2
67 5/8'' X57mm SCREW 2
68 1/2 NUT 4
69 M10X23mm WASHER 4
70 25mm BUSHING 8
71 NUT CAP 4
72 CRANK NUT 2
73 LEFT CRANK 1
74 RIGHT CRANK 1
75 SHAFT BUSHING 2
NO. PART QTY
76 JOINITER 2
77 M8X30mm WASHER 2
78 RETAINING RING 2
79 M26 CURVED WASHER 4
80 M16X28 WASHER 2
81 M8 NUT 3
82 38mm END CAP 2
83 31.8mm END CAP 2
84 13.7 X 10X8 CAP 4
85 016mm BUSHING 4
86 032 BUSHING 4
87 M6 X 72mm SCREW 1
88 TENSION KNOB 1
835 ELLIPTICAL PARTS LIST
CONTINUED
16
FUNCTIONS
Your CardioMax 835 console allows you to use a countdown
function on the Time, Calories and Distance readouts. If any one
of these is not set before beginning your workout, then they will
count up instead of counting down. The console also allows you
to set a high and low pulse rate that you would like to stay within
(an audible beep will alert you when you are out of the pulse rate
range you set). If you do not set a pulse rate range before begin-
ning your workout, then it will simply give you your pulse rate
reading without any audible beeps.
TIME Count Up – Calculates total workout
time up to 99:59
Count Down – Counts down from the
preset time to 00:00
SPEED Calculates current speed
CALORIES Count Up – Calculates total calories burned
up to 999
Count Down – Counts down from the preset
calories entered to 0.0
