Parts List
Kenmore MODEL Nos. 625.384260 and 625.394260
A. WATER SOFTENER COMPLETE
Key No. Part Number Part Description
1 ---- Cover Lock (Required for shipping only)
1 ---- Rim Insert (Required for shipping only)
2 7284396 Cover (main)
3 7284435 Salt Hole Cover (order following decal)
- 7284443 Instruction Decal
4 7088033 Clamp Retainer (2 required)
5 7176292 Clamp Section (2 required)
6 7232446 Vapor Barrier
7 7288578 Timer Repl. (PWA) Model 38426
- 7288586 Timer Repl. (PWA) Model 39426
8 7275907 Transformer, 24 V - 10 VA
9 7229956 Faceplate (order following decal)
7286306 Faceplate Decal
10 7284736 Rim (includes key no. 11 & 12)
11 7252268 O-Ring, 11/16” x 1-1/32”
12 7286021 Light Asm.
13 7265025 Ultra Cleansing Screen
14 7219888 Brinewell Cover, with decal
15 7082150 Wing Nut, 1/4”
16 7003847 O-Ring, 1/4” x 1/2”
17 7109871 Brinewell
18 7214236 Decal, Salt Level
19 7287158 Salt Storage Drum
20 7284613 Plastic Screw, 1/4” x 5/8”
21 0900431 Tube Clamp
22 1103200 Tube Adaptor
23 9003500 Grommet
24 7239155 Brine Valve Asm (see pages 48 & 49 also)
25 7105047 Replacement Distributor
26 0502272 Resin
27 7287190 Resin Tank (includes key no. 26)
28 7170270 O-Ring, 2-3/4” x 3”
29 7077870 Top Distributor
30 7170254 O-Ring, 13/16” x 1-1/16”
31 7170296 O-Ring, 2-7/8” x 3-1/4”
3442699 Resin Bed Cleaner
7287213 Parts Bag (includes parts marked with a pages 47,
49 & 51). Order manuals separately if needed.
7282611 Owner’s Manual
Not illustrated.
Aligns with top of brinewell.
Included in parts bag.
