Kicker VCVR15 - Manual (Page 3)

VCVR12
2 or 4
95
800 (400)
11 9/16 (29.4)
14 13/16 (37.6)
16 (40.6)
17 1/2 (44.5)
4 5
INST
ALLA
TION
Note: The use of a subsonic filter will significantly increase the power handling. The power handling specifications in these charts are
calculated using a 25Hz, 24dB per octave subsonic filter. Measurements based on 4 ohm voice coil models. All specifications and
performance figures are subject to change. Please visit the www.kicker.com for the most current information.
PERFORMANCE
Model:
Nominal Impedance [Zn], ohm [per enclosure]
Sensitivity [SPLo], dB @ 1W, 1m
Power Handling Watts, Peak (RMS)
Enclosure Top Surface Depth, in (cm)
Enclosure Bottom Surface Depth, in (cm)
Enclosure Height, in (cm)
Enclosure Width, in (cm)
DCVR12
2 or 4
98
1600 (800)
13 15/16 (35.4)
17 3/8 (44.1)
16 (40.6)
32 1/2 (82.6)
DCVR10
2 or 4
96.5
1600 (800)
13 7/16 (34.1)
16 7/16 (41.8)
14 (35.6)
28 1/2 (72.4)
VCVR15
2 or 4
97.5
1000 (500)
13 (33.1)
16 7/8 (42.9)
18 7/8 (47.9)
20 5/16 (51.6)
Performance
Model:
Nominal Impedance [Zn], ohm [per enclosure]
Sensitivity [SPLo], dB @ 1W, 1m
Power Handling Watts, Peak (RMS)
Enclosure Top Surface Depth, in (cm)
Enclosure Bottom Surface Depth, in (cm)
Enclosure Height, in (cm)
Enclosure Width, in (cm)
Mount Brackets to the bottom of the
enclosure using the supplied smaller
screws. Securely attach the enclosure to
the vehicle with the supplied larger screws.
(VCVR Series is illustrated)
Figure 4
SafetyWarning
To avoid potential injury, or possible death, from forward movement of the enclosure during abrupt
stops or accidents, the enclosure must be properly installed and securely fastened to your vehicle. You
are solely responsible for securely fastening the enclosure in your vehicle.
R
e
mo
te
T u
rn-On
B
atter
y +
1
2
V
Fu
se
1
8"
Or
L
ess
(45cm)
M
ini
mum
i mp
e d
an
c
e
of
2
ohm
s
mo
n o
- +
2
4
"
Or
L
ess
(60
cm)
Gr
ou
n
d
Signal O
u
t
(P
.A.
S
.T
.)
Signal In
+ _
Mo
n
o
S
p
ea
k
er

F
ig
u
re
3
COMPVRSUBWOOFERENCLOSURE
Pro T
ip:
You are one ZX Mono-Amplifier and a few cables away from a
slamm’in system! The Kicker ZX line of mono-amplifiers make it easy to upgrade to rock-solid bass with your existing or stock source unit. Please ask your dealer about the Kicker ZX Amplifier upgrades. (ZX 400.1 Mono Amplifier wiring diagram and VCVR12 is illustrated)
CompVR Subwoofer - Covered by one or more of the following patents:
U.S. Pat #'s 6,611,604, 6,731,773 D473,216, D456,386, D449,293,
D355,193, Taiwan Pat. #162,154; Other U.S. and foreign patents pending.
