OVEN CHASSIS PARTS
8
For Models:KGRT607HWH5, KGRT607HBT5, KGRT607HBS5, KGRT607HBL5
(White) (Biscuit) (Stainless Steel) (Black)
8187601
Illus. Part
No. No. DESCRIPTION
1
8053421 Module, Spark
98997 Clip
2 9750514GM Chassis, Front
5 9753335GM Oven Liner
6
9755179 Gasket Oven
7
Oven, Side L or R
9781907PW White
9781907PB Black
9781907PC Biscuit
8
9780664 Shield, Insulation
9
9751789 Fan Duct, Side
10
9782329 Duct
11
9752637 Burner Box
12
9752735 Retainer,
Insulation
13
9751653 Duct, Top
14
9751060 Support, Fan
15
9750223 Drawer Rail, Left
9750224 Drawer Rail, Right
16
9751020 Motor, Fan
17
9750147 Bottom Rail (2)
18
312701 Foot, (4)
19
9782005 Hinge, Door L or R
21
9782051 Shield, Drawer
22
9782050 Plate, Reflectance
23
9780265 Screw, 10−16 x 3/8
24
9782326 Shield, Heat
25
9751592 Vent Tube
29
9781581 Door Switch
30
9751808 Screw, 8−18 x 1
31
9780270 Screw, 8−18 x 3/8
