SanDisk uSSD 5000 Product Manual
© 2007 SanDisk® Corporation 11 August 2007
2.8 Physical Specifications
SanDisk offers the uSSD 5000 in 2 form factors:
• Standard profile
• Low profile
Table 12 and Figure 2, Figure 3 and Figure 4 list the physical specifications
and dimensions of the uSSD 5000.
Table 12: Physical Dimensions
Dimension Parameters
Weight 4.9g
Length Standard and Low Profile: 37.80 ± 0.25 mm
Width Standard and Low Profile:26.65 ± 0.25 mm
Thickness Standard profile: 10.60 ± 0.25 mm
Low Profile: 6.58 ± 0.25 mm
2.8.1 Standard Configuration
Figure 2: uSSD Standard Version, Top View
Figure 3: uSSD Standard Version, Bottom View
