EPSON Perfection 1200
4 - EPSON Perfection 1200 8/99
Safety approvals UL 1950
CSA C22.2 No. 950
EN 60950
IEC 950
EMC FCC Part 15 subpart B class B
CSA C108.8 class B
AS/NZS3548 Class B
CE Marking Low voltage directive 73/23/EEC
EN60950
EMC Directive 89/336/EEC
EN55022 Class B
EN50082-1
IEC 801-2/801-3/801-4
Resistance to Panel: 10 kV
electrical noise Metal: 7 kV/150 pF, 150 ohm
(static electricity)
Document
Transparencies up to 4 × 5-inch film
specifications (negative film, positive film)
35 mm strip film (negative, positive)
35 mm slides (negative, positive)
Brownie size strip film
Optional Auto Document Feeder
Specifications
The auto document feeder (B813142) allows you to
automatically load multi-page documents into your scanner.
This document feeder is particularly useful for OCR (optical
character recognition) scanning. You can load up to 20 legal
size (8 1/2 × 14-inches) pages in the auto document feeder.
Basic Specifications
Dimensions Width: 12.6 inches (319 mm)
Depth: 17.8 (451 mm)
Height: 5.4 inches (137 mm)
Weight 4.9 lb (2.2 kg)
Feeder type Sheet through, face up loading, face down
ejecting, roller friction
Loading position Left side of paper against left side of feeder
Connector
8-pin DIN male
Temperature Operation: 50 to 90 °F (10 to 32 °C)
Storage: –4 to 140 °F (–20 to 60 °C)
Humidity Operation: 20% to 80%
(without Storage: 10% to 85%
condensation)
Operating Ordinary office or home conditions; avoid
conditions extreme dust, direct sunlight, and strong
light sources.
Reliability Load/eject: MCBF 20,000 sheets
Hinge: MCBF 12,000 cycles
Electrical Input voltage: DC 24 V ±10%
DC 5 V ±5%
Input current: 24 V: 0.8 A
5 V: 0.2 A
Safety approvals UL 1950
CSA C22.2 No. 950
EN60950 (VDE)
IEC950 (ROSTEST, PSB)
EMC FCC Part 15 Subpart B Class B
CSA C108.8 Class B
AS/NZS3548 Class B
CISPR Pub 22 Class B
CNS13438 Class B
CE Marking Low voltage directive 73/23/EEC
EN60950
EMC Directive 89/336/EEC
EN55022 Class B
EN50082-1
IEC 801-2/801-3/801-4
Resistance to Casing: 10 kV
electrical noise Metal: 7 kV/150 pF, 150 ohm
(static electricity)
ADF Document Specifications
Feeder capacity 20 sheets of maximum weight 55 gm
paper, total thickness less than 0.16 inch
(4 mm)
Size Width: 3.3 to 8.5 inches (85 to 216 mm)
Length: 5 to 14 inches (127 to 356 mm)
Thickness 0.0028 to 0.0063 inch (0.07 to 0.16 mm)
Ream weight 110 to 231 lb (50 to 105 kg)
Paper quality High-quality paper, bond paper, check
paper, recycled paper
Applied color Color and monochrome
Document type Documents printed with impact printers,
laser printers, or fax machines
Don’t use the following paper types:
transparencies, film, coated paper, labels,
carbon paper, or paper with staples, holes, rips,
curls, or folds.
