VPL-AW15
40" to 200" (Diagonally) BRAVIA® AW Series LCD Projector
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Vertical Keystone: Yes
Standby Mode: Yes
Information Menu: Horizontal and Vertical
frequency display
Acceptable Computer Signals: fH: 19 to 92
kHz, fV: 48 to 92 Hz, fV: 60 Hz
Input A: Analog RGB, Component
Video
Video Processing: Yes
Vertical Position: Yes
Acceptable Video Signals: Composite
Video; Y/C Video; 15kHz RGB/Composite,
50/60Hz; Progressive Compomnent
50/60Hz; DTV (480/60i, 575/50i,
720/60p, 720/50p, 1080/60i, 1080/50i);
via HDMI™ only: 1080/60p, 1080/50p,
1080/24p
Panel Driver: 12-Bit
10-bit Video Processing: Yes
Convenience
Multiple Language Display: 15 languages
(including English, French, Spanish,
German, and Chinese)
Power Save Mode: On, Off
Auto Input Search: Yes
Image Flip: HV, H, V, Off
Remote Control: Yes (Backlit)
Specifications
General
Lens: f21.3 to 34.1mm/ F2.4 to 3.1mm
Projection Picture Size: 40" to 200"
measured diagonally
Television Type: HD Front Projectors
Display
Screen Size (measured diagonally): 40" to
200" measured diagonally (projected)
Display Resolution: 1280 x 720 (HD)
Aspect Ratio: 16:9
Video
Native Resolution: 720p
Contrast Ratio: Up to 12,000:1 (with
Advanced Iris Auto ON)
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 1
(Rear)
Composite Video Input(s): 1 (Rear) Vp-
p+/-2 dB sync negative (75 ohms
terminated)
S-Video Input(s): Y/C mini DIN 4-pin type, Y
(luminance): 1 Vp-p+/-2 dB sync negative
(75 ohms terminated) C (chrominance):
burst 0.286 1 Vp-p+/-2 (NTSC) sync
negative (75 ohms terminated) burst 0.3
1 Vp-p+/-2 dB (PAL) sync negative (75
ohms terminated)
PC Video Input(s): 1 (Rear) fH:19 to 92
kHz/fV: 48 to 92Hz/ Maximum resolution:
1920 x 1080 fV: 60Hz
HDMI™ Connection(s) (Total): 1 (Rear)
Digital RGB/Y/Cb(Pb)Cr(Pr)
RS-232C Input(s): Yes
Power
Power Consumption (in Operation): 265W
Power Consumption (in Standby): 0.5W
Power Requirements: AC 100-240V, 1.05-
2.65A, 50/60Hz
Graphics
Format(s) Supported: Supports 1920 x
1080 fV: 60Hz PC timing over HDMI™
Operating Conditions
Operating Temperature: 41° F to 95° F (5° C
to 35° C)
Operating Humidity: 35% to 85%
( condensation)
Service and Warranty Information
Limited Warranty Term: Product Warranty -
2 Years Parts and Labor except the lamp.
Lamp Warranty - 90 days from date of
purchase.
Dimensions
Weight: 12lbs 12oz (5.8kg)
Supplied Accessories
Instruction Manual
Remote Control (RM-PJAW10)
Air Filter
AA Battery x2
Lens Cap
Optional Accessories
DynaClear Screen™ (VPS-80DS)
Replacement Lamp (LMP-H160)
Replacement Air Filter
Suspension Support (PSS-H10) - White
UPC Code: 027242703094
4
1. ANSI lumen is a measuring method of the American National
Standards Institute IT7.228. Since there is no uniform method of
measuring brightness, specifications will vary among manufactures.
2. Conditions: Lamp Control Low and Advanced Iris ON.
3. Lamp Mode Low, not guaranteed.
4. Limited to resolutions supported by both the PC and the Sony TV. See
Sony TV user manual and PC documentation for supported
resolutions.
©2007 Sony Electronics Inc. Sony and BRAVIA are tradmarks of Sony. This
projector incorperated High-Definition Multimedia Interface (HDMI)
technology. HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI Licensing LLC.
All other trademarks are property of their respective owners
Features and specifications are subject to change without notice. Non-
metric weights and measurements are approximate.
