5
Figure 2. Inserting a PC Card
Insert with
label facing
up
Inserting/Removing the PC Cards
Inserting the PC Card: There's only one way the PC Card
can be inserted into the slot. Do not try to force it in if you
meet some resistance. In most systems, the PC Card
should be inserted with the label facing up towards the
top of your system. See Figure 2 for proper orientation.
Removing the PC Card: Simply push the ejector lever
and the PC Card will slide out from the card slot. See
Figure 1
on page 2 for more details.
Ejector lever
