Input/output connectors
CCU CA-TX7: Kings triaxial connector
(made by Lemo)
CA-TX7P: Fischer triaxial
connector
PROMPTER OUT
BNC, 1.0 Vp-p, 75
Ω
RETURN OUT BNC, 1.0 Vp-p, 75
Ω
INTERCOM/PROGRAM
XLR 5-pin
Input level: –60 dBs (dynamic)
Output level: –
∞
to +12 dBs
MIC IN 1,2 XLR 3-pin, female, 600
Ω
,
balanced
Input level: –60 dB (for
microphone input) or –20 dB (for
line input)
DC IN XLR 4-pin, 10.5 to 17 V DC
DC OUT 4-pin, 10.5 to 17 V DC, max. 12 W
DATA 10-pin
Analog: 0 to 5 V DC
×
4
Digital: 0 or 5 V DC
×
2
Camera connector
PRO 76-pin DIGITAL or PRO 50-
pin
Accessories supplied
Operating instructions (1)
Accessories not supplied
Triaxial cable (Belden)
CCQX-3 DC Power Cord
CMA-8A/8ACE AC Adaptor
WRR-810A UHF Portable Tuner
Design and specifications are subject to change
without notice.
Specifications
