-E42-
SPECIFICATIONS
DVD Receiver (DWM-4500)
DVD Video Player
Signal format: NTSC color
Laser: Semiconductor laser, wavelength 650/790 nm
Wow and flutter: Below measurable level
FM Tuner
Frequency range: 87.9 MHz ~ 107.9 MHz (200 kHz steps)
Usable sensitivity: 20.2 dBf (mono)
Inputs/Outputs
SYSTEM: System cable terminal
FM ANT.: FM antenna terminal
PHONES: Stereo headphones jack
General
Dimensions (W x H x D):
Approx. 11.9" x 8.5" x 5.3" (302 x 215 x 134 mm)
Weight: Approx. 4.7 lbs (1.7 kg)
Sub-woofer
(Powered Speaker, ASX-DWM-4500W)
Amplifier
Front Amplifier
Continuous minimum sine wave RMS power output
per channel into 4 ohms at 1kHz with no more than
10% total harmonic distortion (with Center/Sub-
woofer amplifier off) ................................ 100 Watts
Center Amplifier
Continuous minimum sine wave RMS power output
into 4 ohms at 1kHz with no more than 10% total
harmonic distortion (with Front/Sub-woofer ampli-
fier off) ....................................................... 100 Watts
Sub-woofer Amplifier
Continuous minimum sine wave RMS power output
into 4 ohms at 100Hz with no more than 10% total
harmonic distortion (with Front/Center amplifier
off) .............................................................. 100 Watts
Inputs/Outputs
SYSTEM: System cable terminal
AUX (L/R): 1 V/47 kΩ
S-VIDEO OUT:
Y: 1.0 Vp-p (75 Ω) C: 0.286 Vp-p (75 Ω)
VIDEO OUT: 1.0 Vp-p (75 Ω)
COMPONENT VIDEO OUT:
Y: 1.0 Vp-p (75 Ω) P B , P R : 0.7 Vp-p (75 Ω)
SPEAKERS:
FRONT (L/R): 4 Ω CENTER: 4 Ω
REAR OUT: Assistant speaker cable output jack
Transmitter
Built-in type, 914.1 MHz ~ 915.3 MHz, 4ch selectable
Subwoofer
Unit used (non-magnetic shield):
5.1" (13 cm) diameter, Cone type
Maximum power handling capacity: 110 W (peak)
Nominal impedance: 4 Ω
General
Power requirements: AC 120 V, 60 Hz
Power consumption: 76 W
Dimensions (W x H x D):
Approx. 6.1" x 1.8" x 16" (154 x 415 x 407 mm)
Weight: Approx. 20.5 lbs (9.3 kg)
Front Speaker (DWM-4500S)
Unit used (magnetic shield):
3.1" (8 cm) diameter, Cone type, Full range
Maximum power handling capacity: 100 W (peak)
Nominal impedance: 4 Ω
Dimensions (W x H x D):
Approx. 3.8" x 8.5" x 3.7" (96 x 216 x 95 mm)
Weight: Approx. 2.9 lbs (1.3 kg) (per speaker)
Center Speaker (DWM-4500C)
Unit used (magnetic shield):
3.1" (8 cm) diameter, Cone type x 2
1" (2.5 cm) diameter, Tweeter x 1
Maximum power handling capacity: 100 W (peak)
Nominal impedance: 4 Ω
Dimensions (W x H x D):
Approx. 10.7" X 3.9" X 3.1" (272 X 98 X 78 mm)
Weight: Approx. 2.9 lbs (1.3 kg)
Rear Speaker
(Powered Speaker, ASX-DWM-4500R)
Amplifier
Surround Amplifier
Continuous minimum sine wave RMS power output
per channel into 4 ohms at 1kHz with no more than
10% total harmonic distortion ................. 50 Watts
Unit used (non-magnetic shield):
3.1" (8 cm) diameter, Cone type x 2
Maximum power handling capacity: 60 W (peak)
Nominal impedance: 4 Ω
Input/Output
REAR IN: Assistant speaker cable input jack
EXTERNAL SPEAKERS (L/R): 4 Ω
Receiver
Built-in type, 914.1 MHz ~ 915.3 MHz, 4ch selectable
General
Power requirements: AC 120 V, 60 Hz
Power consumption: 30 W
Dimensions (W x H x D):
Approx. 18.9" x 4.7" x 7.6" (480 x 120 x 193 mm)
Weight: Approx. 10.6 lbs (4.8 kg)
IMPORTANT INFORMATION
Because its products are subject to continuous improvement,
Sanyo reserves the right to modify product designs and
specifications without notice and without incurring any obligation.
