Sanyo VMC-8613B User Manual
Vmc-8613b, Service manual color video monitor

VMC-8613B
FILE NO.
REFERENCE No.SM5310559
L8MW5/US2
NOTE: 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N.S.P. : Not available as service parts.
Design and specifications are subject to change without notice.
(Product Code : 114 952 23)
(U.S.A, Canada)
SERVICE MANUAL
Color Video Monitor
CONTENTS
SPECIFICATIONS .................................................................... 3
1. OPERATING INSTRUCTIONS ............................................. 4
2. DISASSEMBLY ..................................................................... 6
3. SERVICE ADJUSTMENTS ...................................................
7
4. PARTS LIST ....................................................................... 10
CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS ........... C1
