SATO S8404 Standard - Manual (Page 10)

9001162 Rev. B
No. Part Number Description
53 P13823010 SHAFT(RIBBON UW)
54 P17518000 DRY METAL
55 P13890000 SHAFT(TENSION ROLLER)
56 PT1114080 BALL BEARING
57 P17737000 BEARING HOLDER
58 P17021000 PULLEY FRAME
59 R07786000 RW PULLEY L
60 PT9740300 POLY SLIDER
61 P13824010 SHAFT(RIBBON RW)
62 P13908000 GEAR PULLEY(20/48)
63 P13822000 SHAFT(GEAR PULLEY)
64 P17472000 MAGNET CATCH
65 R08086020 CAM PULLEY SET
66 P13825000 SHAFT(CAM)
67 P17394000 CABLE COVER(STD)
68 P17805000 CABLE COVER(OPP)
70 R08707000 HEAD UP SENSOR CABLE SET -LF
71 R08708000 HEAD OPEN SENSOR CABLE SET -LF
72 K00171010 STEPPING MOTOR
73 P13985000 MOTOR PULLEY(S2M 16)
74 P17019000 MOTOR PLATE(RIBBON)
75 P17057000 SPRING(RIBBON MOTOR)
76 P17020000 MOTOR BR(RIBBON)(STD)
77 P17064000 MOTOR BR(RIBBON)(OPP)
78 PU3256060 MINI PITCH BELT
79 P17886000 TIMING BELT
80 K00213000 STEPPING MOTOR
82 P02525000 RUBBER DAMPER
83 P11157001 MO PULLEY
84 P17025000 MOTOR PLATE
85 P17991000 TIMING BELT
86 R07576000 MOTOR BR(SAVER) SET (STD)
87 R07583000 MOTOR BR(SAVER) SET (OPP)
88 P17518000 DRY METAL
89 P17058000 SPRING(SAVER MOTOR)
90 P17400020 SHAFT(TENSION D)
9001162 Rev. B
No. Part Number Description
91 P18956000 PULLEY(S2M 24)
92 P13863000 TENSION ROLLER
93 P17401010 SHAFT(TENSION C)
94 R07926010 GEAR FRAME(OPP) SET
95 R07587010 GEAR FRAME(STD) SET
96 P11157001 MO PULLEY
97 K00173000 STEPPING MOTOR
98 P17402000 SPRING(BELT TENSION)
99 P17398000 TENSION BR B
100 P17067000 PULLEY(18/27/60)
101 P17073000 SHAFT(GEAR FRAME C)
102 P17069010 GEAR PULLEY(52/57/64)
103 P13863000 TENSION ROLLER
104 R07927000 TENSION PLATE(OPP)SET
105 R07588000 TENSION PLATE(STD)SET
106 P17810010 SPRING(TENSION)(OPP)
107 P17102010 SPRING(TENSION)(STD)
108 P17280000 TENSION LINK
109 P17070010 GEAR(FEED)
110 P23325000 TIMING BELT
111 P23324000 TIMING BELT
112 P23326000 TIMING BELT
113 NB2040022 TOOTHED LOCK WASHER
114 NB2030022 TOOTHED LOCK WASHER
116 R07452010 S-KB PCB SUB ASSY -LF
117 R08697010 AC LINE CABLE SET -LF
119 G00209000 ROCKER SWITCH -LF
120 P21580000 VOLUM COVER
121 P18934000 PCB PROTECTOR
122 P17411010 DISPENSE GUIDE B(STD)
123 P17803010 DISPENSE GUIDE B(OPP)
124 P17169000 SHAFT(TENSION A)
125 P17518000 DRY METAL
126 R08700021 KB CABLE SET -STD -LF
127 R08762021 KB CABLE SET -OPP -LF
