SINGER 14J334 - Manual (Page 10)

SERIAL NO.
14J334
CA05561
March, 1999
SERGER MODEL 14J334
66725
10963
61588
67444
72795
62309
63805
72135
65818
73973
72639
73900
67251
72747
77014
67444
61588
10963
66725
72794
72768
66725
73973
35942
72818
72135
73900
63805
61222
72775
72793
72821
64359
72642
72827
72705
53740
43393
66725
72787
77013
72767
61222
66725
BUYER'S MODEL NO.
BUYER'S MODEL NAME
FACTORY MODEL
ORIGINAL ISSUE DESCRIPTION SECTION PAGE REVISION REMARKS
'
72640
10963 E6 CLIP-ON-WASHER
35942 THRUST WASHER
43393 WASHER
61222 M4 PHILIPS SCREW
61588 WASHER
62309 M3 SCREW
63805 WASHER
64359 M4 SCREW
65818 M4 BOLT
66725 M4 SCREW
67251 M3.5 PHILIPS SCREW
67444 COLLAR
72135 THREAD GUIDE (B)
72639 LOOPER BASE
72640 UPPER LOOPER SUPPORTING ARM
72642 PIVOT
72747 NEEDLE RECEIVER (A)
72767 BED COVER
72768 LOOPER COVER
72775 THREAD GUIDE (A)
72787 PIN
72793 LOOPER SLIDE SHAFT
72794 SHAFT
72795 SHAFT
72818 PIN
72821 COLLAR
72827 THREAD GUIDE
73900 M3 PHILIPS SCREW
73973 M4 BOLT
77013 UPPER LOOPER
77014 LOWER LOOPER
