Parts identification
For explanation of the use of each part, see pages indicated in parentheses.
Main unit
SELECT button
(14, 15, 20)
MENU +, –
buttons (15)
MEGA BASS
button (25)
REPEAT/ENTER
button
(16, 21, 22)
DC IN 6V (external
power input) jack
(5, 8)
Battery
compartment (27)
Continue to the next page m
^ (play/pause)
button (7, 8, 9)
VOLUME control (8)
p (stop) button
(7, 9)
OPEN button (6, 8)
Remote sensor (10)
ESP button (24)
RETURN ˆ
button (15)
PLAY MODE
button (20 - 24)
= button
(7, 9, 16, 18)
RESUME switch
(17, 26)
HOLD switch (25)
+ button
(7, 9, 16, 18)
AUDIO/VIDEO OUT
(output) jack (5, 17, 26)
NTSC/PAL switch (6)
PHONES/REMOTE
(headphones/remote
control) jack (8, 9)
