MAINTENANCE INSTRUCTIONS
4.23
CONTROL ASSEMBLIES
ITEM
PART NO.
QTY.
DESCRIPTION
ITEM
PART NO.
QTY.
DESCRIPTION
1 SCR125
4 1
5/8
IN BIND HEAD SCREW
• 18
GEA-002 1
HELICAL
GEAR
2 SCR008
4 1
1/4
IN BIND HEAD SCREW
ο 19
PIN008 1
ROLL
PIN
3 BLT008
1 HEXAGONAL BOLT
20
66404-1
1
GEAR SHAFT
ο
4
WSH019
1
WASHER
21
BBS-005
1
OILITE BEARING
ο
5 68901 1 CRANK
ARM
22 NUT025
4 STOP
NUT
6 BBS-004
1 BRAKE
BUSH
23 66103
66101-4
1
1
SAFETY CONNECTOR
CABLE PLUG
7
81800-10
2
CONTROL CRANK HOUSING
24
59125
2
25 FT (7.6 M) HOUSING
8
68900-8
1
CRANK DECAL
59135
2
35 FT (10.7 M) HOUSING
9
68900-4
2
BRAKE JAW
59150
2
50 FT (15.2 M) HOUSING
10
68900-3
1
BRAKE ARM
25
55005
1
50 FT (15.2 M) CONTROL CABLE
11
BBS-001
2
BALL BEARING ASSEMBLY
55010
1
70 FT (21.3 M) CONTROL CABLE
12 68900-7 1 WEAR
STRIP
55009 1 100 FT (30.5 M) CONTROL CABLE
13 81800-1 1 DRIVE
WHEEL
26 69303 1 ODOMETER
ASSEMBLY
•
14 68900-2 2 CABLE
ADAPTER
27 69201-3
1 HANDLE
•
15 69302-1 1 GEAR
SHAFT
•
28
66410
1
FRAME
ο
16 BBS-007
1 OILITE
BEARING
•
29
66403
1
ODOMETER
ASSEMBLY
ο
17 PIC-003 1 WASHER
•
• PISTOL GRIP MODEL
ο REEL TYPE MODEL
14
1
2
1
2
3
4
5
6
7
8
9
9
10
11
12
13
11
7
20
21
18
19
22
19
18
17
16
15
24
23
23
25
