Lift lever kit – Snapper 3538 User Manual
Page 3
3
TP 400-3538-00-AT-SMA
Lift Lever KIt
1
1927557
2
NUT, Flange, 5/16-18
2
1931333
4
CARRIAGE BOLT, 5/16-18 x 3/4
3
1722291
1
GRIP, Lift Lever
4
1723124
1
BUTTON, Red Nylon, for 1/4 Rod
5
1960518
1
NUT, Push
6
1723321
1
SPRING, Compression, Lift Lever
7
1721581
1
QUADRANT, Lift, Powdered Metal
8
1926149
6
CAPSCREW, 5/16-18 x 1, G8
9
1721712
1
LEVER ASSEMBLY, Lift
10
1960636
5
NUT, Hex, 5/16-18
11
1722482
1
ROD, Latch
12
1722112
1
LOCK, Lift, Powdered Metal
13
156302
1
SPRING, Extension
14
1723163
1
SPACER, 1/2 x 3/4 x 23/32
15
1723795
1
BAR, Lift Link
16
1919381
7
WASHER, 5/16, Black
17
1921160
1
CAPSCREW, Hex Head, 5/16-18 x 2-1/4
18
1722819
1
PIN, Flat Head, 1/2 x 2-1/8
19
1960033
1
CLIP, Hair Pin, 2-9/16 Long
20
1721654
1
SHAFT ASSEMBLY, Lift
21
1935255
1
NUT, Speed, 5/16-18, Lug
22
1675232
1
SPRING, Extension
23
1723499
1
RETAINER, Spring Flat
24
1722357
1
CAPSCREW, Hex Head, 5/16-18 x 4-1/2
25
1724378
1
COVER, Hand Control
26
1707514
2
CHAIN, 3-Link
27
1930570
2
CAPSCREW, Hex Head, 5/16-18 x 1-1/2
28
1919438
2
NUT, Nylock, 5/16-18
29
1724432
2
ARM, Lift, Duel, Mower
30
1931277
4
NUT, Whizlock, 5/16-18
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1694148
Lift Lever Kit
