Low Input / Line Output Wiring
Two Channel Amplifiers:
D400.2, D650.2 and D1000.2 Amplifiers
Four Channel Amplifiers:
D350.4 and D500.4 Amplifiers
Hi Input Wiring
2 Channel Amplifiers 4 Channel Amplifiers
To OUTPUT
of HEAD UNIT
To OUTPUT
of HEAD UNIT
To INPUT ADDITIONAL
AMPLIFIER
To INPUT ADDITIONAL
AMPLIFIER
CH1+ CH2+
CH1- CH2-
G
CH3+ CH4+
CH3- CH4-
G
CAR STEREO CAR STEREO
CHASSIS
GROUND CHASSIS
GROUND CHASSIS
GROUND
If the HIGH LEVEL INPUTS are used, do not use the LOW LEVEL RCA inputs at the same time.
The 2-Channel amplifiers use ONE High Level input for both channels and the 4-Channel amplifier use TWO of
these connectors-one for each pair of channels.
Remote
Subwoofer Level
Control
Remote
Subwoofer Level
Control
