FEATURES OPERATING INSTRUCTIONS
How To Assemble & Use
Your Hand Held Steam Cleaner utilizes pressurized steam to remove tough grease,dirt
and grime.
Steam is nature’s purest and most powerful cleaner for safely cleaning all hard
surfaces in your home without harsh chemicals, thus being perfectly ecological. The appliance has
various attachments so that it can be used for many purposes such as:
1. Clean upholstery, sealed grout, bathroom/kitchen tile, stovetops.
2. Easy to clean difficult to reach areas with the angle adapter or concentrator such as
faucets, etc.
3. Ideal for windows, mirrors, glass doors, etc.
4. Clean fabrics, window coverings, pillows, bedding etc.
5. Clean hard surface areas such as counters, sinks, shower door tracks, etc.
CAUTION:
Do not plug in the machine during filling. Use a grounded
receptacle. Use only a heavy duty extension cord rated for 15
amps - Do not use an ordinary extension cord.
IMPORTANT: Do NOT add cleaning solutions, scented perfumes, oils or
any other chemicals to the water used in this appliance.
Use regular water or distilled/purified water if the tap
water in your area is very hard.
WARNING: Your Hand Held Steam Cleaner is designed to clean hard
surfaces and upholstery that will withstand high heat. Do not use on soft
plastics,unsealed wood and cold glass. On surfaces that have been treated with
wax or some no wax floors, the sheen may be removed by the heat and steam
action. Do not use on unsealed wood. This could cause the wood grain to rise. It
is therefore recommended to test an isolated area of the surface to be cleaned
before proceeding.
4
Steam Shut off Safety
Note: This unit must always be used with an accessory to function. The accessory
actuates the Steam Shut off Safety for use. Do not try top defeat this Steam Shut
Off mechanism.
When attaching or removing hose or concentrator from the main unit, an integrated
safety is engaged preventing the user from inadvertently releasing hot steam. Always
release the locking trigger button before removing accessories.
NOTE: There may be a slight release of pressure when accessories are removed.
This is normal due to pressure build up inside of accessories during use.
When refilling the water tank, ensure that either the steam concentrator or steam hose is
attached to main unit.
To refill, unplug, unit from electrical outlet, depress trigger until all remaining
pressure/steam has been allowed to escape from the tank, and allow to cool for 5
minutes. Carefully open the safety cap. Once cool, refill, replace safety cap and re-plug
into electrical outlet. Resume work.
Step 1: Before filling the steam cleaner,
make sure that the unit is NOT
plugged in.
Step 2: Press locking trigger to ensure
all internal pressure is released.
Step 3: Turn Safety Cap counter
clockwise until removed.
Step 4: Release locking trigger.
Step 5: Add water using the filling flask
provided. Do not overfill.
Replace Safety Cap by turning
clockwise - press down firmly to
tighten. Heating time is
approximately 6 minutes. Filling
the boiler with hot water will
shorten heat up time.
Step 6: Plug the unit into a standard
120 volt grounded wall
receptacle. The power “On”
light (Red) will light up.
Step 7: Allow approximately 6 minutes
for water vapor to reach its
working temperature and
pressure. When unit is ready
for use the red light will change
to Green.
Step 8: At the start, some water will
come out from the nozzle. This
is normal.
NOTE: Disconnect steam cleaner from
wall outlet before refilling. It is time to refill
your steam cleaner when there is no more
steam coming out of the nozzle. Because
the water tank is pressurized, use caution
when opening to refill. Depress the trigger
button while you unscrew the safety cap
counterclockwise. Always let unit cool for
5 minutes before refilling the unit with
water.
CAUTION: When refilling the appliance
while it is still hot, the first drops of
water might bubble up.
Refilling With Water
Using the Locking Trigger Button
The steam cleaner has a locking trigger
button. The trigger will lock when you
have pushed it all the way. To unlock
the trigger, just press down on the
trigger release and the trigger will pop
up, stopping the flow of steam.
IMPORTANT: Always insure that the
unit is “UNPLUGGED” from the wall
receptacle prior to initial filling or re-filling
the water tank. Never attempt to fill this
unit under a water tap, always use the
filling flask provided. Failure to follow
these steps will cause the water tank to
overfill and may pose an electrical safety
hazard.
Step 1: Disconnect electrical power
cord from wall outlet.
Step 2: Press trigger button until all
pressure has been released.
Step 3: Allow the unit to cool for
approximately 5 minutes
before refilling with water.
Carefully unscrew safety cap.
Step 4: Slowly pour water using the
filling flask into the boiler.DO
NOT Fill Under a faucet, use
the filling flask provided. DO
NOT OVERFILL. Always
leave approximately an inch
between the top of the unit
and the water level.
Step 5: Release the locking trigger.
Step 6: Screw safety cap back on the
appliance and plug appliance
back into wall outlet. Steam will
start to be produced as before.
WARNING: This appliance is under
pressure. After every use, press
trigger button until all
pressure has been released before
removing safety cap. Either
concentrator nozzle or hose must be
connected in order for the trigger to
operate. Allow unit to cool for three (3)
minutes before refilling.
5
