FCC Verifi cation:
NOTE: This equipment has been tested and found to comply with the limits for
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are de-
signed to provide reasonable protection against harmful interference in a residen-
tial installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try to cor-
rect the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna
· Increase the separation between the equipment and the receiver
· Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
· Consult the dealer or an experienced radio/TV technician for help
IMPORTANT NOTE: Prohibition against eavesdropping
Except for the operations of law enforcement offi cers conducted under lawful
authority, no person shall use, either directly or indirectly, a device operated pursu-
ant to the provisions of this Part for the purpose of overhearing or recording the
private conversations of others unless such use is authorized by all of the parties
engaging in the conversation.
WARNING: Modifi cations not approved by the party responsible for compliance
could void user’s authority to operate the equipment.
IMPORTANT SAFETY INSTRUCTIONS:
· Make sure product is fi xed correctly and stable if fastened in place
· Do not operate if wires and terminals are exposed
Before You Begin
2 7
Troubleshooting Guide
Technical Specifications
Problem: I can’t see the camera on my TV.
Solution: Ensure the camera is plugged in and the TV or VCR is tuned to the
correct input channel.
Problem: The image is too far away.
Solution: Change the lens to the larger telephoto lens for a zoomed in image.
Unscrew the attached lens and replace with telephoto lens.
Problem: The BNC Extension Cable will not connect to my TV.
Solution: Connect the BNC to RCA adapter to the end of the Extension Cable
and plug into the TV.
Problem: On my Swann DVR, Video Loss appears where my camera should be.
Solution: Check the Extension cable is securely connected to the camera and
check the connection is secure on the back of the DVR. Also ensure the camera
has power by trying a second power outlet.
7
Video
Image Sensor
1/3” Colour Super CMOS
Video Quality 400 TV Lines
Number of Effective Pixels NTSC: 510 x 492 / PAL: 628 x 582
Signal / Noise Ratio > 50dB
Electronic Shutter 1/60 - 1/15,000 NTSC / 1/50 - 1/15,000 PAL
White Balance Automatic
Gain Control Automatic
Backlight Compensation Yes
Day/Night Mode Colou-r during the day / Switches to B&W at night
Minimum Illumination 0 Lux (IR on)
Lens 4mm
Viewing Angle 90 degrees
General
Indoor/Outdoor
Indoor Only
Operating Power DC 12V
Operating Temperature 0°C ~ 45°C / 32°F ~ 113°F
Body Construction Heavy duty plastic
Dimensions - Camera & Stand 4.25” x 2.75” x 1.75” / 108mm x 69mm x 44mm
Weight – Camera & Stand
4.2oz / 125g
