L-1782-BH-01
4.
Parts Reference
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
19
20
22
23
25
26
27
28
29
30
31
32
33
PART NO.
B-983
B-1673P
C-123
R-618
R-635-01
R-636
R-637-01
R-640
R-653
R-704
R-705-10
R-713-10
R-746
R-755-10
R-1503
R-1835-10
R-2466-10
R-2474-10
R-2473-10
R-775-10
R-803
10M0840P
11M1016P
30M1000P
40M1000P
45M1111P
45M1717P
R-2469-01
R-2475-01
R-2476-10
DESCRIPTION
Hair pin cotter
Hex Lock Nut, 1/4"
Gauge wheel
Reinforcing washer (special)
Locking collar
Push nut
Axle
Set screw (slotted), 5/16"
Thatching Tine
Nylon bearing, 1/2"
Wheel support
Bracket (tray mounting)
Lift pin
Tray
Tine Safety wire
Bracket (lift)
Mounting frame
Lift handle rear
Lift lock bracket
Handle retaining strap
Handle grip
Carriage bolt, 1/4" x 2-1/2"
Carriage bolt, 5/16" x 1"
Hex nut, 5/16"
Lock Washer, 5/16"
Plain Washer, 5/16"
Plain Washer, 1/2"
Rod, Small
Rod, Large
Handle Extention
QTY.
1
4
2
10
2
2
2
2
10
4
2
2
1
1
2
1
1
1
1
1
1
4
21
23
21
3
4
1
1
1
Parts List
