REF.NO.

PART NO.

DESCRIPTION

REMARK

REF.NO.

PART NO.

DESCRIPTION

REMARK

The components identified by mark

are critical for safety.
Replace only with part number specified.

Les composants identifiés par une
marque

sont critiques pour la sécurité.

Ne les remplacer que par une pièce
portant le numéro spécifié.

CPD-E220/E220E/E215E

7-7

(d)

#4 R401

1-227-370-11

RES-CHIP

1.82K

1/10W 419A118212

#4 R402

1-227-370-11

RES-CHIP

1.82K

1/10W 419A118212

#4 R403

1-260-298-51

CARBON (SMALL) 3.3

1/2W 4050133955

R404

Pending

METAL OXIDE FILM 0.75

4171075856

R406

1-243-478-11

CARBON (SMALL) 1.5

1/4W 4050515955

#4 R407

1-260-322-51

CARBON (SMALL) 330

1/2W 4050133155

R408

Pending

CARBON (SMALL) 3.3K

1/2W 4050133254

R409

Pending

RES-CHIP

10K

1/10W 4010110202

R411

1-242-988-11

METAL FILM

6.81K

1/4W 4257046811

R412

1-242-988-11

METAL FILM

6.81K

1/4W 4257046811

#4 R500

1-247-798-11

CARBON (SMALL) 43

1/4W 4050543055

#4 R501

1-216-083-11

RES-CHIP

27K

1/10W 4010127352

#4 R502

1-227-372-11

RES-CHIP

22.1K

1/10W 419A122122

#4 R503

1-216-065-11

RES-CHIP

4.7K

1/10W 4010147252

#4 R504

1-227-379-11

RES-CHIP

732

1/10W 419A173202

R505

Pending

RES-CHIP

2.8K

1/10W 4010128202

#4 R506

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

#4 R507

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

#4 R508

1-249-430-11

CARBON (SMALL) 12K

1/4W 4050512355

#4 R509

1-247-844-11

CARBON (SMALL) 3.6K

1/4W 4050536255

#4 R510

1-216-025-11

RES-CHIP

100

1/10W 4010110152

#4 R511

1-216-025-11

RES-CHIP

100

1/10W 4010110152

#4 R512

1-216-198-11

RES-CHIP

1/8W 4010810252

#4 R513

1-216-025-11

RES-CHIP

100

1/10W 4010110152

R515

Pending

RES-CHIP

68K

1/10W 4010168302

#4 R516

1-247-846-11

CARBON (SMALL) 4.3K

1/4W 4050543255

#4 R517

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

#4 R518

1-218-769-11

RES-CHIP

510K

1/10W 4010151452

#4 R519

1-244-194-11

METAL OXIDE 100

4172010156

R520

Pending

METAL OXIDE FILM 0.22

4171022856

R521

Pending

METAL FILM

22.6K

1/4W 4257042262

#4 R522

1-216-065-11

RES-CHIP

4.7K

1/10W 4010147252

[E220/E220E]

#4 R522

1-216-041-11

RES-CHIP

470

1/10W 4010147152

[E215E]

#4 R523

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

#4 R524

1-216-071-11

RES-CHIP

8.2K

1/10W 4010182252

#4 R525

1-243-482-11

CARBON (SMALL) 56

1/4W 4050556055

#4 R526

1-216-065-11

RES-CHIP

4.7K

1/10W 4010147252

#4 R527

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

R528

Pending

METAL FILM

120

1/2W 4077B12155

#4 R529

1-249-417-11

CARBON (SMALL) 1K

1/4W 4050510255

#4 R530

1-244-277-11

METAL OXIDE 1.8

417731895A

#4 R531

1-216-055-11

RES-CHIP

1.8K

1/10W 4010118252

[E220/E220E]

#4 R531

1-215-049-91

RES-CHIP

1/10W 4010110252

[E215E]

#4 R532

1-260-312-51

CARBON (SMALL) 47

1/2W 4050147055

R533

Pending

METAL OXIDE 1.3K

4177113253

R534

Pending

METAL OXIDE 10

4171010053

#4 R535

1-249-417-11

CARBON (SMALL) 1K

1/4W 4050510255

#4 R536

1-216-069-11

RES-CHIP

6.8K

1/10W 4010168252

R537

Pending

CARBON (SMALL) 15K

1/4W 4050115355

#4 R538

1-216-065-11

RES-CHIP

4.7K

1/10W 4010147252

#4 R539

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

#4 R540

1-260-364-51

CARBON (SMALL) 1M

1/2W 4050110555

#4 R543

1-242-979-11

METAL OXIDE 270

4177127153

#4 R544

1-260-352-51

CARBON (SMALL) 100K

1/2W 4050110455

#4 R545

1-260-352-51

CARBON (SMALL) 100K

1/2W 4050110455

[E220/E220E]

#4 R547

1-249-425-11

CARBON (SMALL) 4.7K

1/4W 4050547255

[E220/E220E]

#4 R549

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

[E220/E220E]

R551

Pending

RES-CHIP

10K

1/10W 4010110202

R552

Pending

RES-CHIP

100K

1/10W 4010110402

R553

Pending

RES-CHIP

100K

1/10W 4010110402

#4 R554

1-216-154-11

RES-CHIP

1/8W 4010815052

#4 R555

1-247-807-31

CARBON (SMALL) 100

1/4W 4050510155

#4 R556

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

R557

Pending

METAL OXIDE 10

4171010053

#4 R558

1-249-431-11

CARBON (SMALL) 15K

1/4W 4050515355

#4 R559

1-249-417-11

CARBON (SMALL) 1K

1/4W 4050510255

#4 R560

1-216-101-11

RES-CHIP

150K

1/10W 4010115452

#4 R561

1-249-437-11

CARBON (SMALL) 47K

1/4W 4050547355

#4 R562

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

#4 R563

1-249-437-11

CARBON (SMALL) 47K

1/4W 4050547355

#4 R565

1-215-049-91

RES-CHIP

1/10W 4010110252

#4 R566

1-249-429-11

CARBON (SMALL) 10K

1/4W 4050510355

#4 R567

1-216-073-91

RES-CHIP

10K

1/10W 4010110352

#4 R568

1-249-429-11

CARBON (SMALL) 10K

1/4W 4050510355

#4 R569

1-260-326-51

CARBON (SMALL) 680

1/2W 4050168155

#4 R570

1-216-057-91

RES-CHIP

2.2K

1/10W 4010122252

#4 R571

1-249-425-11

CARBON (SMALL) 4.7K

1/4W 4050547255

#4 R572

1-249-393-11

CARBON (SMALL) 10

1/4W 4050510055

#4 R573

1-247-868-91

CARBON (SMALL) 36K

1/4W 4050536355

#4 R574

1-216-095-11

RES-CHIP

82K

1/10W 4010182352

#4 R575

1-216-662-11

RES-CHIP

1/10W 4010130252

R576

1-242-973-11

METAL OXIDE 30K

4177330355

R577

Pending

CARBON (SMALL) 68

1/4W 4050568055

#4 R578

1-249-417-11

CARBON (SMALL) 1K

1/4W 4050510255

#4 R579

1-216-059-11

RES-CHIP

2.7K

1/10W 4010127252

#4 R580

1-216-025-11

RES-CHIP

100

1/10W 4010110152

[E220/E220E]

#4 R580

1-216-041-11

RES-CHIP

470

1/10W 4010147152

[E215E]

R581

Pending

CARBON (SMALL) 33K

1/4W 4050533355

#4 R582

1-249-422-11

CARBON (SMALL) 2.7K

1/4W 4050527255

#4 R583

1-244-277-11

METAL OXIDE 1.8

417731895A

#4 R584

1-249-089-11

RES-CHIP

47K

1/10W 4010147352

#4 R585

1-249-401-11

CARBON (SMALL) 47

1/4W 4050547055

R586

Pending

METAL FILM

110K

1/4W 4257041103

R589

Pending

METAL FILM

10K

1/4W 4257041002

#4 R590

1-247-903-81

CARBON (SMALL) 1M

1/4W 4050510555

#4 R591

1-216-091-11

RES-CHIP

56K

1/10W 4010156352

#4 R592

1-216-089-11

RES-CHIP

47K

1/10W 4010147352

R594

Pending

RES-CHIP

120K

1/10W 4010112452

#4 R595

1-216-065-11

RES-CHIP

4.7K

1/10W 4010147252

R596

Pending

82K

1/10W 4010182302

R597

Pending

CARBON (SMALL) 82

1/2W 4050182055

#4 R598

1-215-049-91

RES-CHIP

1/10W 4010110252

[E220/E220E]
