Samsung MAX-B550 - Manual (Page 9)

Samsung
Electronics
2-5
2-4
SPEAKER
Exploded
V
iew
a
nd
Parts
list
1
2
3
4
5
PS B550E/H :
AH81-00640A
No.
Description
Code No.
Q'TY
1
P
ANEL ASS
'Y
AH81-00640Q
1
2
UNIT TWEETER
AH81-00609R
1
Specification
PANEL+P/GRILLE+PIEZO
F20T
-D253-1
3
UNIT W
OOFER
AH81-00640J
1
5
WHITE CONE
4
W
OOFER RING
AH81-00640E
1
HIPS BLK
5
CABINET ASS'Y
AH81-00640G
1
PB 9t / 12t
* CAUSION : It is used the bonding, connet NET
FRAME(or FRONT
P
ANEL
ASS’Y) to CABINET
ASS’Y
.
So when the disassembly
, take extreme care not to demage the SPEAKER.
2-4-1 MAXB550/MAXZB550
