3 TP 400-2385-00-AT-SMA
Lift Lever - Regent
1 1650157 1 BUTTON
2 1713995 1 GRIP
3 1704718 1 LEVER ASSEMBLY
4 1934953 1 PUSH NUT, 5/16
5 1667286 1 SPRING
6 1657648 1 LATCH, Lift Lever
7 1667290 1 ROD
8 1704715 1 BRACKET
9 1674669 1 SPACER
10 1919438 4 LOCKNUT, 5/16-18
11 1704716 1 SPACER
12 1921977 4 CAPSCREW, Hex Head 5/16-18 x 1-1/4
13 1675795 2 SPACER
14 1665591 1 QUADRANT, Lift
15 1921719 1 CAPSCREW, Hex Head, 3/8-18 x 2-1/2
16 1927609 1 ROLL PIN, 3/8 x 1
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692623 Lift Lever - Regent
