Assembly requires two people. Place all parts of the exercise cycle in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed. Read through all steps before
beginning. During assembly, make sure that all parts are oriented as shown in the drawings.
Assembly requires the included tool and grease packet, an adjustable wrench , a rubber
mallet , and a phillips screwdriver .
Use the drawings below to identify the small hardware used in assembly. The number in parenthesis beneath
each part refers to the key number of the part, from the PART LIST on page 10. The second number refers to
the quantity used in assembly. Note: some of the hardware shown below may have been pre-attached.
ASSEMBLY
3/16Ó Small Screw (2)Ð15
M8 Spring Washer (3)Ð4 M8 Locknut (32)-8
1/2" Locknut (23)-2
5/8" Push Cap (35)-2
Link Arm Bushing (47)-2
Pedal Bushing (25)-2
M8 Washer (5)-4
M6 x 16 Screw (49)-8
3/8" Push Cap (19)-2
