16 GB
Required cords
A Speaker cords (not supplied)
(+)
B Monaural audio cord (not supplied)
Black
(–)
* If you have an additional front speaker system, connect them to the SPEAKERS FRONT B terminals. You can
select the front speakers you want to use with the SPEAKERS (OFF/A/B/A+B) button. For details, see “Selecting
the speaker system” (page 42).
FRONT A
CENTER FRONT B
MONITOR
OUT
NT VIDEO
Y
P B /C B
/B–Y
P R /C R
/R–Y
L R
L R
L R
+ + – –
–
SPEAKERS
AUDIO
OUT
SUB
WOOFER
A
E e
A
E e
A
E e
E e
A
INPUT
AUDIO
IN
B
E e
A
SPEAKERS
FRONT B*
E e
A
SURROUND
SPEAKERS
L R
+
SURROUND BACK
Sub woofer
Center speaker Surround back
speaker
Front speaker
(Left)
Front speaker
(Right)
Surround speaker
(Right)
Surround speaker
(Left)
