Function Overview
– 9 – EN
Setup
Hint Hint
• To go back one step, hit [s] (during the
steps 2) to 7) ).
• Your clock setting will be lost if either there
is a power failure or this unit has been
unplugged for more than 30 seconds.
6 6
CLOCK SET
MONTH DAY YEAR
1 0 / 0 3 MON 2 0 0 5
HOUR MINUTE AM/PM
0 5 : 4 0 – –
7 7
CLOCK SET
MONTH DAY YEAR
1 0 / 0 3 MON 2 0 0 5
HOUR MINUTE AM/PM
0 5 : 4 0 P M AM
B PM
Select “AM” or “PM”.
8 8 To exit the CLOCK SET
screen
Select the current minute.
or or
Front Panel Indicator
Because this product is a combination of a VCR and
a DVD player, you must select first which compo-
nent you wish to operate with [SOURCE].
A
G H
Y X
y
AUDIO
VIDEO REW F.FWD STOP/EJECT RECORD IR
REC TIMER B B C C A D E
CHANNEL
OPEN/
CLOSE
SOURCE
X Y VCR DVD DISC IN PLAY
PREV NEXT STANDBY-ON PLAY STOP PLAY
X Y
VCR DVD
SOURCE PREV
SOURCE button
DVD OUTPUT
light
VCR OUTPUT
light
DVD button
VCR button
STANDBY-ON
DISPLAY VCR DVD PAUSE
SLOW
VCR/TV
SKIP/CH.
PLAY
STOP
RECORD
MENU
SETUP TOP MENU
MODE ZOOM
SUBTITLE T-SET ANGLE
ENTER
RETURN
SEARCH MODE
REPEAT A-B
OPEN/CLOSE /EJECT SPEED AUDIO
CLEAR/ C. RESET
1 2 3
4 5 6
7 8 9
0 +10
Hit [VCR] on the remote control.
(Verify that the VCR OUTPUT light is lit.)
VCR MODE
Hit [DVD] on the remote control.
(Verify that the DVD OUTPUT light is lit.)
DVD MODE
Hint Hint
• Hitting only [SOURCE] on the front panel DOES NOT
switch the mode of the remote control. You MUST select
the correct mode on the remote control.
A
G H
Y X
y
AUDIO
VIDEO REW F.FWD STOP/EJECT RECORD IR
REC TIMER
B B C C A D E
CHANNEL
OPEN/
CLOSE
SOURCE
X Y
VCR DVD DISC IN PLAY
PREV NEXT STANDBY-ON PLAY STOP PLAY
Lights up when the inserted disc is being played back.
Flashes when an unacceptable disc is installed. Lights up when the Timer Recording
or an OTR recording has been set.
Lights up during a recording.
Flashes when a recording is paused.
Lights up when a disc is installed.
VCR/DVD Switching
