Appendix E – Physical specification *
Depth: 325mm/12.8 inches not including heatsink
365mm/14.3 inches including heatsink
400mm/15.75 inches including connectors
Height: 89mm/3.5 inches (2 RU)
Width: 480mm/19 inches
Weight: 5kg/11 pounds
Power: 55 Watts/67 VA
Boxed size: 520mm x 520mm x 182mm (20.5" x 20.5" x 7.2")
Boxed weight: 7.3kg (16 pounds)
* All weights and dimensions are approximate
Appendix F – Environmental Specification
Temperature Operating: 5 to 30 Deg. C
Non-operating: –20 to 50 Deg. C
Max. Gradient: 15 Deg. C/Hour
Relative Humidity Operating: 20 to 80 %
Non-operating: 5 to 90 %
Max. wet bulb: 29 Deg. C (non-condensing)
Vibration Operating: < 0.2 G (3 - 100Hz.)
Non-operating, power off: < 0.4 G (3 - 100Hz.)
Shock Operating: < 2 G (10mSec. Max.)
Non-operating: < 10 G (10mSec. Max.)
Altitude Operating: 0 to 3000m (above sea level)
Non-operating: 0 to 12000m
