- 10 -
PARTS LIST
REF.NO. PART NO. DESCRIPTION
or
405 000 0904 TR DTA114YS
or 405 078 2404 TR BN1A4P
Q2452 405 078 2404 TR BN1A4P
or 405 000 0904 TR DTA114YS
or 405 151 5209 TR KRA107M
or 405 036 3702 TR 2SA1564
Q2453 405 036 3702 TR 2SA1564
or 405 151 5209 TR KRA107M
or 405 000 0904 TR DTA114YS
or 405 078 2404 TR BN1A4P
Q4410 405 141 3406 TR KTA1266-GR
or 405 141 3505 TR KTA1266-Y
or 405 004 4502 TR 2SA608-F-NP
or 405 004 5004 TR 2SA608-G-NP
Q4501 405 000 3806 TR DTC114YS
or 405 143 0007 TR KRC107M
Q4502 405 143 0007 TR KRC107M
or 405 000 3806 TR DTC114YS
Q4600 405 155 0002 TR MPSA56
Q4601 405 000 3806 TR DTC114YS
or 405 143 0007 TR KRC107M
Q4602 405 019 3804 TR 2SC536-G-NP
or 405 019 2708 TR 2SC536-F-NP
or 405 141 3307 TR KTC3198-GR
or 405 141 3208 TR KTC3198-Y
Q4603 405 141 3208 TR KTC3198-Y
or 405 019 2708 TR 2SC536-F-NP
or 405 141 3307 TR KTC3198-GR
or 405 019 3804 TR 2SC536-G-NP
Q4700 405 000 3806 TR DTC114YS
or 405 143 0007 TR KRC107M
Q4800 405 000 3806 TR DTC114YS
or 405 143 0007 TR KRC107M
Q4950 405 141 3307 TR KTC3198-GR
or 405 019 2708 TR 2SC536-F-NP
or 405 019 3804 TR 2SC536-G-NP
or 405 141 3208 TR KTC3198-Y
Q4960 405 155 0002 TR MPSA56
Q4961 405 155 0002 TR MPSA56
Q4962 405 000 3806 TR DTC114YS
or 405 143 0007 TR KRC107M
Q4963 405 000 3806 TR DTC114YS
or 405 143 0007 TR KRC107M
Q4990 !!! 405 138 6403 TR KTD2058Y
or !!! 405 095 1602 TR 2SD2061-E
or !!! 405 095 1701 TR 2SD2061-F
Q4991 !!! 405 095 1602 TR 2SD2061-E
or !!! 405 095 1701 TR 2SD2061-F
or !!! 405 138 6403 TR KTD2058Y
Q4992 405 141 3703 TR KTA1271-Y
or 405 008 2405 TR 2SB698-F
or 405 008 2504 TR 2SB698-G
Q4993 405 141 3703 TR KTA1271-Y
or 405 008 2405 TR 2SB698-F
or 405 008 2504 TR 2SB698-G
Q4994 405 000 3806 TR DTC114YS
or 405 143 0007 TR KRC107M
R4742 !!! 402 071 1304 FUSIBLE RES 2.2 JA 1/4W
R4842 !!! 402 071 1304 FUSIBLE RES 2.2 JA 1/4W
S0001 614 317 3007 SHIELD,PLATE
S4901 614 215 9828 SWITCH,TACT
SA401 411 021 6405 SCR S-TPG BIN 3X8
SA402 411 021 6405 SCR S-TPG BIN 3X8
SA403 411 021 6405 SCR S-TPG BIN 3X8
SA404 411 021 6405 SCR S-TPG BIN 3X8
SA405 411 021 6405 SCR S-TPG BIN 3X8
SH201 614 310 5404 SHIELD,ANTENA
REF.NO. PART NO. DESCRIPTION
T2002
645 046 2023 FILTER,450KHZ
U2101 645 043 6697 TUNER,FM
X2451 645 023 4965 OSC,CRYSTAL 7.2MHZ
XF221 645 010 7665 CERAMIC FILTER 10.70MHZ
or 645 010 0079 CERAMIC FILTER 10.70MHZ
or 614 240 2917 FILTER,CERAM
XF222 645 010 7665 CERAMIC FILTER 10.70MHZ
or 645 010 0079 CERAMIC FILTER 10.70MHZ
or 614 240 2917 FILTER,CERAM
XF231 645 041 9324 CERAMIC FILTER 450KHZ
XF233 645 039 9923 TRANS,IF 10.7MHZ
or 645 040 9981 TRANS,IF 10.7MHZ
POWER TRANSFORMER,
PRIMARY P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
74
614 314 9613 ASSY,PWB PT1 (Only Initial)
CN411 614 017 8203 TERMINAL BOARD
CN412 614 017 8203 TERMINAL BOARD
L4191 !!! 645 041 3087 INDUCTOR,180U
or !!! 645 038 6053 INDUCTOR,181U
or !!! 645 017 8061 INDUCTOR,181M
POWER TRANSFORMER,
SECONDARY P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
75
614 314 9620 ASSY,PWB PT2 (Only Initial)
CN420 614 020 1222 SOCKET,3P
CN421 614 316 8003 ASSY,WIRE,PT-AMPWIRE
D4280 !!! 407 196 5800 DIODE 1N5402BD82
D4281 !!! 407 196 5800 DIODE 1N5402BD82
D4282 !!! 407 196 5800 DIODE 1N5402BD82
D4283 !!! 407 196 5800 DIODE 1N5402BD82
D4284 !!! 407 098 3300 DIODE RL153-BF-S2
FCL41 !!! 645 006 4760 HOLDER,FUSE
or !!! 645 031 7903 HOLDER,FUSE
FCL42 !!! 645 006 4760 HOLDER,FUSE
or !!! 645 031 7903 HOLDER,FUSE
PR420 !!! 645 014 2567 PROTECTOR,2.5A 125V
CD LID SWITCH P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
76
614 316 5170 ASSY,PWB CD LID SW (Only Initial)
S1900 645 044 8782 SWITCH,LEVER
S1901 645 044 8799 SWITCH,LEVER
