- 9 -

PARTS LIST

REF.NO. PART NO. DESCRIPTION
S6218

614 240 1002

SWITCH,TACT

or

645 006 5958

SWITCH,PUSH 1P-1T

or

614 220 5471

SWITCH,TACT

S6219

645 006 5958

SWITCH,PUSH 1P-1T

or

614 240 1002

SWITCH,TACT

or

614 220 5471

SWITCH,TACT

S6220

645 006 5958

SWITCH,PUSH 1P-1T

or

614 240 1002

SWITCH,TACT

or

614 220 5471

SWITCH,TACT

SE601

407 217 1101

PHOTO DIODE SPS-442-1G

X6101

645 032 1627

OSC,CRYSTAL 32.768KHZ

X6102

645 018 6103

OSC,CERAMIC 6.000MHZ

614 317 3397

CUSHION

TUNER & AMPLIFIER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION
73

614 314 5028

ASSY,PWB AMP-TU (Only Initial)

C2457

403 259 0508

NP-ELECT 1U M 50V

C4601

403 057 3503

POLYESTER 0.1U K 50V

C4605

403 061 3605

POLYESTER 0.039U J 50V

C4606

403 061 7702

POLYESTER 4700P J 50V

C4607

403 059 3204

POLYESTER 2200P J 50V

C4608

403 060 2807

POLYESTER 0.027U K 50V

C4743

403 057 3503

POLYESTER 0.1U K 50V

C4843

403 057 3503

POLYESTER 0.1U K 50V

C4950

403 332 7400

ELECT 2200U M 50V

C4984

403 194 3800

ELECT 2200U M 25V

or

403 329 3309

ELECT 2200U M 25V

CN201

614 255 5750

TERMINAL

or

645 032 6394

TERMINAL

CN400

645 012 5362

SOCKET,FPC 32P

CN430

645 005 7373

PLUG,3P

or

614 310 2441

PLUG,3P

CN431

407 218 1100

PHOTO COUPLE GP1FA550TZ

or

407 215 1608

PHOTO COUPLE TOTX178A

CN440

614 310 2472

PLUG,6P

or

645 005 8127

PLUG,6P

CN441

614 310 2748

PLUG,3P,POWER

or

645 004 2898

PLUG,3P,POWER

CN445

614 310 2519

PLUG,10P

or

645 005 8158

PLUG,10P

CN450

614 276 6835

SOCKET,JACK

CN455

645 011 6384

JACK,PHONE D3.6,HEADPHONE

CN456

645 006 1875

PLUG,2P,SPEAKER

CN457

645 006 1875

PLUG,2P,SPEAKER

CN458

645 043 8905

JACK,RCA

CT251

645 032 5236

TRIMMER,18PF

CT252

645 032 5663

TRIMMER,7PF

D2103

407 012 4406

DIODE 1SS133

D2104

407 012 4406

DIODE 1SS133

D2151

407 012 4406

DIODE 1SS133

D2153

407 105 1602

VARACTOR DI SVC342M-V

or

407 105 1305

VARACTOR DI SVC342L-V

D2301

407 063 9108

ZENER DIODE MTZJ6.8B

D2450

407 012 4406

DIODE 1SS133

D2451

407 012 4406

DIODE 1SS133

D2452

407 153 7502

ZENER DIODE GZS3.0B

D2453

407 012 4406

DIODE 1SS133

D2454

407 012 4406

DIODE 1SS133

D2455

407 012 4406

DIODE 1SS133

D2456

407 012 4406

DIODE 1SS133

D2466

407 012 4406

DIODE 1SS133

D4500

407 012 4406

DIODE 1SS133

D4960

407 012 4406

DIODE 1SS133

D4991

407 099 6805

ZENER DIODE MTZJ13B

D4992

!!!

407 099 6003

ZENER DIODE MTZJ9.1B

D4993

407 012 4406

DIODE 1SS133

REF.NO. PART NO. DESCRIPTION
D4994

407 098 3300

DIODE RL153-BF-S2

D4998

407 012 4406

DIODE 1SS133

HS401

614 314 3017

HEAT SINK,HEATSINK

IC231

409 474 3201

IC LA1844ML

IC241

409 439 4502

IC LC72121M-D

IC440

409 451 7406

IC AN7348K

IC441

409 500 2208

IC LC75343-MPB

IC442

!!!

409 451 2104

IC TDA7269

IC443

409 189 3404

IC BA7755A

IC445

409 469 6200

IC MM1453XF

IC446

!!!

409 039 9204

IC NJM78L05A

L2100

!!!

645 037 2858

CORE,PIPE

L2101

!!!

645 037 2858

CORE,PIPE

L2151

645 040 2685

TRANS,ANT,796KHZ

L2152

645 046 7998

TRANS,ANT,796KHZ

L2153

645 040 2708

TRANS,OSC,796KHZ

L2154

645 040 2722

TRANS,OSC,796KHZ

L2301

645 004 0580

INDUCTOR,1M J

L2451

645 001 4581

INDUCTOR,100U K

or

645 031 7842

INDUCTOR,100U K

L4600

645 006 1523

INDUCTOR,470U J

L4601

645 006 1523

INDUCTOR,470U J

L4602

645 037 2858

CORE,PIPE

L4603

645 006 1523

INDUCTOR,470U J

L4604

645 037 2858

CORE,PIPE

LUG45

614 129 9068

LUG

LUG46

614 129 9082

LUG

PR495

!!!

645 014 2505

PROTECTOR,0.8A 125V

PR496

!!!

645 014 2512

PROTECTOR,1A 125V

Q2140

405 020 7402

TR 2SC945A-P

or

405 020 7204

TR 2SC945A-K

or

405 019 3705

TR 2SC536-G-AUD-SPA

or

405 017 9709

TR 2SC3330-U

or

405 017 9600

TR 2SC3330-T

or

405 011 8609

TR 2SC1740S-S

or

405 011 8500

TR 2SC1740S-R

or

405 143 8706

TR KTC3199-GR

Q2152

405 016 0806

TR 2SC2839-E

or

405 151 4103

TR KTC3193-Y

or

405 151 4202

TR KTC3193-O

Q2153

405 151 4202

TR KTC3193-O

or

405 151 4103

TR KTC3193-Y

or

405 016 0806

TR 2SC2839-E

Q2154

405 016 0806

TR 2SC2839-E

or

405 151 4202

TR KTC3193-O

or

405 151 4103

TR KTC3193-Y

Q2155

405 016 0806

TR 2SC2839-E

or

405 151 4103

TR KTC3193-Y

or

405 151 4202

TR KTC3193-O

Q2156

405 016 0806

TR 2SC2839-E

or

405 151 4103

TR KTC3193-Y

or

405 151 4202

TR KTC3193-O

Q2157

405 035 8609

TR 2SK544-F

or

405 035 8708

TR 2SK544-E

Q2201

405 016 0806

TR 2SC2839-E

or

405 151 4103

TR KTC3193-Y

or

405 151 4202

TR KTC3193-O

Q2310

405 020 7402

TR 2SC945A-P

or

405 020 7204

TR 2SC945A-K

or

405 019 3705

TR 2SC536-G-AUD-SPA

or

405 017 9709

TR 2SC3330-U

or

405 017 9600

TR 2SC3330-T

or

405 011 8609

TR 2SC1740S-S

or

405 011 8500

TR 2SC1740S-R

or

405 143 8706

TR KTC3199-GR

Q2451

405 036 3702

TR 2SA1564

or

405 151 5209

TR KRA107M
