Appendixes
A-14
Appendixes
Pattern
No. Effect type and adjustable parameters
Effect control parameters (continued)
2710 3D page turn
2711 F1: Direction of turn (Angle = 0 to 100)
F2: Change in turn direction (Curve = –100 to +100)
F3: Radius of turn (Radius = 0 to 100)
F4: Adjustment of effect end position (EndAdj= –100 to +100)
F6: Amount of X-axis rotation (Rot_X = –100 to +100)
F7: Amount of Y-axis rotation (Rot_Y = –100 to +100)
F8: Amount of Z-axis rotation (Rot_Z = –100 to +100)
F9: Perspective (Pers = 0 to 100)
F10: Delay before start of turn (Delay = –100 to +100)
X/Y/Z: Location, enlargement, and reduction of the pattern
2712 3D page turn
2713 F3: Radius of turn (Radius = 0 to 100)
F4: Adjustment of effect end position (EndAdj= –100 to +100)
F6: Amount of X-axis rotation (Rot_X = –100 to +100)
F7: Amount of Y-axis rotation (Rot_Y = –100 to +100)
F8: Amount of Z-axis rotation (Rot_Z = –100 to +100)
F9: Perspective (Pers = 0 to 100)
F10: Delay before start of turn (Delay = –100 to +100)
X/Y/Z: Location, enlargement, and reduction of the pattern
2714 3D page turn
2715 F3: Radius of turn (Radius = 0 to 100)
F4: Adjustment of effect end position (EndAdj= –100 to +100)
F6: Amount of X-axis rotation (Rot_X = –100 to +100)
F7: Amount of Y-axis rotation (Rot_Y = –100 to +100)
F8: Amount of Z-axis rotation (Rot_Z = –100 to +100)
F9: Perspective (Pers = 0 to 100)
F10: Delay before start of turn (Delay = –100 to +100)
X/Y/Z: Location, enlargement, and reduction of the pattern
2720 3D twist
F1: Direction of twist (Angle = 0 to 99)
F2: Change in twist direction (Curve = –100 to +100)
F3: Area of the part that twists (Area = 0 to 100)
F6: Amount of X-axis rotation (Rot_X = –100 to +100)
F7: Amount of Y-axis rotation (Rot_Y = –100 to +100)
F8: Amount of Z-axis rotation (Rot_Z = –100 to +100)
F9: Perspective (Pers = 0 to 100)
F10: Delay before start of twist (Delay = –100 to +100)
X/Y/Z: Location, enlargement, and reduction of the pattern
3D twist
F3: Area of the part that twists (Area = 0 to 100)
F4: Type of twist (TYPE = TYPE01/TYPE02/TYPE03/TYPE04)
F6: Amount of X-axis rotation (Rot_X = –100 to +100)
F7: Amount of Y-axis rotation (Rot_Y = –100 to +100)
F8: Amount of Z-axis rotation (Rot_Z = –100 to +100)
F9: Perspective (Pers = 0 to 100)
F10: Delay before start of twist (Delay = –100 to +100)
X/Y/Z: Location, enlargement, and reduction of the pattern
Effect Control Parameter List
2721
to
2724
(continued)
