Mechanical Equipment
Gear Drive Units
Manufacturer Model Ratio
Oil Level: Full q Add Immediately q Low, check again soon q
Oil Condition: Good q Contains Water q Contains Metal q Contains Sludge q
Oil Used—type
Seals
Back
Lash
Fan Shaft End Play
Any Unusual Noises? No q Yes q Action Required:
Drive Shafts
Manufacturer Material
Fans
Manufacturer Fixed Pitch q Adjustable Pitch q
Diameter Number of Blades
Blade Material
Hub Material
Hub Cover Material
Blade Assembly Hardware
Blade Tip Clearance " min. " max.
Vibration Level
Fan Cylinder Height
Mech. Eqpt. Support Mat’l
Oil Fill & Drain Lines
Oil Level Sight Glass
Vibration Limit Switches
Other Components
Motor
Manufacturer
Name Plate Data: hp RPM Phase Cycle Volts
F.L. Amps Frame S.F. Special Info.
Last Lubrication—Date
Grease Used—Type
Any Unusual Noise? No q Yes q Action Required
Any Unusual Vibration? No q Yes q Action Required
Any Unusual Heat Build-up? No q Yes q Action Required
1 2 3 Comments
inspection checklist
Condition: 1—Good 2—Keep an eye on it 3—Needs immediate attention
