DAY

NIGHT

Weatherproof Camera

VCC-XZ200P

Pan-Focus Day/Night Weatherproof Zoom Camera

CAMERA
• 1/4” Interline Transfer Method CCD

• IP66 Rated

• External Housing

• 520 TV Lines of Horizontal Resolution

• Minimum Illumination 1.2 Lux (F1.9, Colour Mode)

0.06 Lux (F1.9, B/W Mode)

• 2.6 X Motorised Zoom Pan-Focus Lens

• Motion Detection

• Privacy Masking

• Remote Zoom / Focus / Menu Set-Up Via Coax

(with Optional VAC-70)

• 24 V AC / 12V To 15V DC

• Easy Installation, Adjustment and Set-Up

OPTIONS
• VA-20ST – Twisted Pair, NVT, SSP

• VA-20LAN – Network Option Board (Motion JPEG)

• VA-50H – Heater for Pan-Focus Range

• DPTCH – Pole Mount Adapter

• DCWGH – Corner Mount Adapter

• VA-XZBX – Back box

Accessories for Pan-Focus Cameras

VA-50LAN - Jpeg Expansion board for network connection

for VDC-DP7585P and VCC-P7575PA.

Enables a camera to connect to a network. The user can

operate a network connected camera using a web browser

(Internet Explorer).

VA-51LAN – Jpeg Expansion board for network connection

for Pan-Focus Camera, including PoE (Power over Ethernet)

and bi-directional audio.

VA-50ST – SSP + Twisted pair board for VDC-DP7585P and

VCC-P7575PA. Enables the control via RS-485 (SSP/PELCO-D)

and coaxial cable (SSP/H-SSP/PELCO-C), Twisted pair Terminal

(CAT5) for Video signal (NVT built-in UTP video)

VA-20LAN - Jpeg Network board for Pan-Focus VCC-XZ200P

Enables the cameras to connect to a network. The user

can operate a network connected cameras using a web

browser (Internet Explorer).

VA-20ST – SSP + Twisted pair board for VCC-XZ200P

Enables the control via RS-485 (SSP/PELCO-D) and coaxial cable

(SSP/H-SSP/PELCO-C) , Twisted pair Terminal (CAT5) for Video

signal (NVT built-in UTP video)

VA-50H - Heater board for Pan-Focus VCC-XZ200P,

VDC-DP7585P, VDC-DPN9585P and VDC-DP9585P

The heater board protects the camera from cold weather.

It allows the camera to operate at temperatures of -30°C to +50°C

and with humidity within 90%. (For VDC-DP9585P, AC24V use only)

VA-50BW - Wall mounting bracket (indoor use)

VA-50BPL - Ceiling suspension bracket (long)

VA-50BPS - Ceiling suspension bracket (short)

VA-50AL - VA-50BW attachment (Vandal Resistant Pan-Focus Dome)

VA-50AS - VA-50BW attachment (Internal Pan Focus Dome)

VCZ-50 - Smoked cover for Pan-Focus Camera

VA-DK02 - Flash Mount Bracket for:

Pan-Focus Domes (Internal & Vandal Resistant)

Vandal Resistant Domes

VCC-9685VP

VAC 70

Full technical specification online at www.sanyosecurity.com

SANYO CCTV - Next Generation Technology

OPTION

DAY

NIGHT

VCC-ZM600P

Day/Night Zoom Camera

1/4" CCD, 540Tvl Resolution

30x Optical Zoom & 16x
digital Zoom

IR sensitive with mechanical
IR Cut filter release

Minimum illumination 0.04lx (B/W,
F1.4, Gain High) 0.8lx (colour)

3 mode Backlight
Compensation

13 mode Electronic Shutter
Speeds

32x Sensitivity Boost

Image Stabilizer

Optical Zoom upon Alarm in /

Motion detection

Alarm out upon Motion
detection

External Alarm terminal
In (2) Out (1)

8 Zoom Preset position

2 Pre-defined camera view
settings

4 Privacy masking

Remote Zoom/Focus/Menu
set-up by RS485 & COAX
(Pelco-D, Pelco-C, SANYO
RS485, SANYO COAX, VAC-70)

Twisted pair video (NVT)

DC12-15V/AC24V

30x

VAC 70

VCC-ZM500P

Colour Zoom Camera

1/4" CCD, 540Tvl Resolution

30x Optical Zoom & 16x digital Zoom

Minimum illumination 0.8lx
(Max AGC)

3 mode Backlight Compensation

13 mode Electronic Shutter Speeds

32x Sensitivity Boost

Optical Zoom upon Alarm in /
Motion detection

Alarm out upon Motion detection

External Alarm terminal In (2) Out (1)

8 Zoom Preset position

2 Pre-defined camera view settings

4 Privacy masking

Remote Zoom/Focus/Menu set-up
by RS485 & COAX
(Pelco-D, Pelco-C, SANYO RS485,
SANYO COAX, VAC-70)

DC12-15V/AC24V

R/G/B

30x

VAC 70

30x Zoom Cameras

DAY

NIGHT

VCC-XZ600P

Weatherproof Day/Night Zoom Camera

IP66 weatherproof housing for easy external installation

1/4" CCD, 540Tvl Resolution

30x Optical Zoom & 16x digital Zoom

IR sensitive with mechanical IR Cut filter release

Minimum illumination 0.04lx

(B/W, F1.4, Gain High) 0.8lx (colour)

3 mode Backlight Compensation

13 mode Electronic Shutter Speeds

32x Sensitivity Boost

Image Stabilizer

Optical Zoom upon Alarm in / Motion detection

Alarm out upon Motion detection

External Alarm terminal In (2) Out (1)

8 Zoom Preset position

2 Pre-defined camera view settings

4 Privacy masking

Remote Zoom/Focus/Menu set-up by RS485 & COAX

(Pelco-D, Pelco-C, SANYO RS485, SANYO COAX, VAC-70)

Twisted pair video (NVT)

DC12-15V/AC24V

OPTIONS

DPTCH : Pole Mount Adapter

DCWGH : Corner Mount Adapter

VA-XZBX : Back box

30x

VAC 70

C

A

M

E

R

A

S

18

C

A

M

E

R

A

S

19

NEW

NEW

NEW
