8 Technical
Data
Model
HPC2512
HPC4024
HPC5048 HPC7048
Inverter
Nominal battery voltage
12 V
24 V
48 V
48 V
Input voltage range
9.5 – 17 V
19 – 34 V
38 – 68 V
38 – 68 V
Nominal power @ 25°C
2500 W
4000 W
5000 W
7000 W
Maximum load 30 min. @ 25°C
2800 W
4500 W
6000 W
8000 W
Maximum load 5 sec
3 x Pnom
Maximum load
up to short circuit
Maximum asymmetric load
up to Pnom
Standby adjustment
1 to 25 W
Cos
ϕ
0.1 - 1
Maximum efficiency
93 %
94 %
96 %
96 %
Consumption OFF/Standby/ON
1.4/1.8/10 W
1.7/2/16 W
2/2.5/18 W
2/3/25 W
Output voltage
230 Vac (0 / - 10%)
Output frequency crystal controlled
50 Hz
± 0.05 %
Total harmonic distortion
< 2%
Dynamic behaviour on load change 0
→ 100 %
0.5 ms
Overload and short circuit protection
Automatic disconnection with 3 time restart attempt
Overheat protection
Acoustic warning before shut-off - with automatic restart
Battery charger (4 STEP) I-U-Uo-Equalize (every 25 cycles)
Charging current adjustable
0 – 110 A
0 – 100 A
0 – 70 A
0 – 90 A
Input current balance adjustment (Power Sharing)
1 – 30 A
1 – 30 A
1 – 30 A
1 – 50 A
Maximum input voltage
265 Vac
Minimum input voltage
Adjustable threshold from 150 to 230 Vac
Input frequency
45 – 65 Hz
Power Factor Correction (PFC)
EN 61000-3-2
Battery control (thresholds and times adjustable by the user)
Absorption time
0-4h
End charge cycle voltage
14.4 V
28.8 V
57.6 V
57.6 V
Floating voltage
13.6 V
27.2 V
54.4 V
54.4 V
Equalisation voltage
15.6 V
31.2 V
62.4 V
62.4 V
Deep-discharge protection
10.8 V
21.6 V
43.2 V
43.2 V
Temperature compensation (option CT-35)
-3mV / °C / cell
General data
Multifunction contact - potential free (3 points)
16 A – 250 Vac
Max. current on transfer relay
30 A / 6.9 kVA
30 A / 6.9 kVA
30 A / 6.9 kVA
50 A / 11.5 kVA
Transfer time
< 20 ms
Weight
33 kg
39 kg
41 kg
48 kg
Dimension h x l x L [mm]
242/288/480
242/288/480
242/288/480
242/288/500
IP protection index
IP 20
EEC conformity
EN50081 I/II, EN 55014 – EN 55022, EN 61000-3-2
IEC 801 I/II/III/IV, CEI 555, IEC 1000-3-2, LVD 73/23/EEC
Working range
-20 to 55°C
Ventilation from
45°C
Acoustic level without / with ventilation
< 10 dB / < 35 dB
Recommended battery capacity (C10)
> 5 x Pnom/Unom
Warranty 2
years
Options
Remote control (112 x138 x 25mm / 20 m cable)
RCC-01
Remote power sharing (20 m. cable)
RPS-01
Battery temp. sensor (58 x 51.5x 22mm / 3 m cable)
CT-35
Data may change without any notice
