3 Reserved
4 Program Program mode for Aux.
Contact
5
Contact active Auxiliary Contact is activated
6 Contact
man-
ual
Aux. Cont. manually activated
7
TRANSFER Transfersystem is active. In-
coming voltage is being sent
directly to AC OUT outlet
Transfer (bypass) is disabled
(see chap. 4.7)
8
AC OUT
There is a voltage at the AC
OUT outlet
The Inverter is in Standby-Mode
9
INVERTER
Inverter is working
Forced Inverter Mode (see chap.
4.5)
10
Over Temp.
For the time being the HP-
COMPACT is out of service
because of overheating.
11
Overload
The HP-COMPACT is out of
service because of overload
or short-circuit
12
Batt. Low/High Battery voltage is too low
Battery voltage is or was to high
13
OFF
HP-COMPACT is turned off.
Turning it back on is only pos-
sible manually.
HP-COMPACT is for the time
being turned off. Turning it back
on will follow automatically !
14
EQUALIZE
Battery equalizing is set
15–18
State of charge of the battery LED 15 – Absorption time is run-
ning
25 POWER
MONITOR
Display the value of the output power in % of Pnom (in Inverter
Mode) and the charge current in Amps (in Charger Mode). In this
mode the red LED indicates that power sharing is in use (>100A).
4.3
P
ush buttons
19
ON/OFF
Turning the HP-COMPACT on and off (Help Button for Program-
ming)
20
RESET
Alarm Signal off (Help Button for Programming)
21
Aux. Contact Control Aux. contact (Help Button for Programming)
4.4 Turning
Knobs
22 CHARGER
Adjustment
for
max. Charging Current
23
TRANSFER
Adjustment for Transfer Voltage Threshold (TRANSFER – IN-
VERTER)
24
STANDBY
Adjustment for „Standby“ system
26
INPUT LIMIT Must be adjusted to the maximal available current of your AC
INPUT supply
4.5 The
Inverter
An Inverter is built in the HP-COMPACT, which generates a sinusoidal alternating voltage
of a very high quality. With this Inverter any 230Vac alternating voltage appliance up to the
nominal power of your HP-COMPACT can be operated. Thanks to the generous dimen-
sioning of the HP-COMPACT, you can operate appliances requiring higher power than the
nominal power of the HP-COMPACT for a short time. The HP-COMPACT provides up to
3-times the nominal power to start motors.
