WIRING
POWER AND GROUND
12
less than 10´ more than 10´
HRU. 2
HRU. 4 2 or 4 gauge 2 gauge only
CIRCUIT BREAKERS AND FUSES
EXTERNAL
INTERNAL
Never replace the fuse with a higher value than what is supplied. This may
result in amplifier damage and will void the warranty!
Human Reign Unleashed Amplifier Fuse Values
Like all audio components, the Human Reign Unleashed amplifier must be
fused near the battery. A fuse or circuit breaker must be located within 18” of
the battery. This will prevent a fire in the event of a shorted cable. See the
chart below to determine the correct fuse value.
Battery Fuse / Circuit Breaker
200 amp
2 or 4 gauge 2 gauge only
140 amp
HRU. 2
HRU. 4
To ensure maximum output from your Human Reign Unleashed amplifier,
use high quality, low-loss power and ground cables and connections. The
Human Reign Unleashed amplifiers will accept up to 2 gauge power and
ground cables. Determine from the chart below the minimum gauge power
and ground wire for your application.
The Human Reign Unleashed amplifiers need to be fused with an automotive-type
fuse or circuit breaker. In the event of a blown power supply fuse(s), replace with
replace with the correct value fuse found in the chart below.
