S i 8 2 4 x C l a s s D - K I T
12 Rev. 0.2
2 R16, R17
12.1 k
, 2010 1%
SMT Resistor
ERJ-12SF1212U Panasonic ECG P12.1KACCT-ND
3
R18, R21,
R60
20 k
, 0603 1%
SMT Resistor
ERJ-3EKF2002V Panasonic ECG P20.0KHCT-ND
2 R29, R30
4.99 k
, 0603 1%
SMT Resistor
ERJ-3EKF4991V Panasonic ECG P4.99KHCT-ND
4
R23, R24,
R39, R40
100 k
, 0603 1%
SMT Resistor
ERJ-3EKF1003V Panasonic ECG P100KHCT-ND
1 R25
121 k
, 0603 1%
SMT Resistor
ERJ-3EKF1213V Panasonic ECG P121KHCT-ND
2 R27, R28
1.3 k
, 0603 1%
SMT Resistor
ERJ-3EKF1301V Panasonic ECG P1.30KHCT-ND
2 R31, R32
7.5 k
, 0603 1%
SMT Resistor
ERJ-3EKF7501V Panasonic ECG P7.50KHCT-ND
2 R33, R34
300 k
, 0603 1%
SMT Resistor
ERJ-3EKF3003V Panasonic ECG P300KHCT-ND
3
R19, R41,
R42
2 k
, 0603 1% SMT
Resistor
ERJ-3EKF2001V Panasonic ECG P2.00KHCT-ND
2 R45, R46
511
, 0603 1%
SMT Resistor
ERJ-3EKF5110V Panasonic ECG P511HCT-ND
4 R47–R50
12.1
, 0805 1%
SMT Resistor
ERJ-6ENF12R1V Panasonic ECG P12.1CCT-ND
2 R51, R52
1
, 0805 1% SMT
Resistor
RC0805FR-071RL Yageo 311-1.00CRCT-ND
2 R53, R54
0.005
, 3264 1%
SMT Resistor
MCS3264R005FE Panasonic ECG MCS3264R005FERCT-ND
1 R55
0
, 1206 1% SMT
Resistor
ERJ-8GEY0R00V Panasonic ECG P0.0ECT-ND
1 R61
39.2 k
 0603 1%
SMT Resistor
ERJ-3EKF3922V Panasonic ECG P39.2KHCT-ND
2 HS1
Heatsink TO-220
5W BLK
576802B00000G
AAVID
Thermalloy
HS121-ND
12 TP1-TP12 Test Pad
3103-2-00-21-00-
00-08-0
MILL-MAX
MAN.
ED5052-ND
4
Shoulder
Washer
Washer/bushing #4
X .031"L NYLON
3049 Keystone 3049-ND
Table 1. Si824x Class D Audio Amplifier Reference Design Bill of Materials (Continued)
Qty Ref Description Mfr. Part Number Mfr Digikey Part Number
