S i 8 2 4 x C l a s s D - K I T
10 Rev. 0.2
4 C67–C70
82 µF, 63 V, KZE
Series Electrolytic
Cap
EKZE630ESS820M
JC5S
Chemi-Con 565-1721-ND
4 C71–C74
0.1 µF, 100 V, X7R,
1206 Ceramic
Capacitor
12061C104MAT2A AVX 478-3786-6-ND
4 C75–C78
0.01 µF, 100 V,
COG, 1206 Ceramic
Capacitor
12061C103JAT2A AVX 478-3783-6-ND
2 C79, C80
0.47 µF, 250 V Film
Capacitor
ECQ-E2474KB Panasonic ECG P10975-ND
3 D1–D3
100 V 150 mA
SOD123 Diode
1N4148W-13-F Diodes Inc. 1N4148W-13-FDIDKR-ND
6 D4–D9
Fast Recovery
200 V 2 A Diode
SMA
MURA120T3G On Semi MURA120T3GOSCT-ND
2 ZD1, ZD2
Diode Zener
500 mW 5.1 V
SOD-123
MMSZ4689-TP
Micro
Commercial Co.
MMSZ4689-TPMSCT-ND
1 IC1
IC Voltage Reg 5.0 V
200 mA SOT223
ZSR500GTA ZETEX ZSR500GCT-ND
1 IC3
Adjustable Nega-
tive Regulators SOT-
223
LM337IMP National Semi LM337IMPDKR-ND
2 IC4, IC5
High-Voltage Adjust-
able Regulator
TO220
TL783CKCSE3 TI 296-20687-5-ND
3
IC11, IC12,
IC16
CMOS Comparator
SOT23-5
LMC7211BIM5/
NOPB
National Semi LMC7211BIM5CT-ND
2 IC13, IC14
Single Channel
Digital Isolator
SOIC8
Si8410BB-D-IS Silabs
1 IC15
Voltage Supervisor
with Adjustable
Power-on Reset
SOT23-5
ISL88011IH531Z-
TK
Intersil ISL88011IH531Z-TKDKR-ND
2 IC17, IC18
IC Opamp Audio
Ster AB 8SOIC
LM4562MA/NOPB National Semi LM4562MA-ND
Table 1. Si824x Class D Audio Amplifier Reference Design Bill of Materials (Continued)
Qty Ref Description Mfr. Part Number Mfr Digikey Part Number
