Cleaning and Care (continued)
Door Glass Removal
The oven door is equipped with three sheets of glass placed against each other. These sheets
can be removed for cleaning.
1
Remove the two
screws on the left and
right sides of the door.
2
Detach the covering
and remove glass 1
from the door.
3
Lift glass 2 and
remove the two holder
glass rubber from the
top of the sheet, then
remove glass 3. Clean
the sheets with warm
water or washing-up
liquid and polish dry
them with a soft clean
cloth.
✉ The Door-Glass is different from 2EA to 4EA model by model.
But, the method of the disassembly and assembly is same.
✉ When assembly the inner glass 1, put printing to direction below.
Bulb Exchange
☛ Danger of electric shock!
Before replacing any of the oven bulbs, take the following steps:
● Switch oven Off.
● Disconnect the oven from the mains.
● Protect the oven light bulb and the glass cap by laying a cloth on the bottom of
the oven compartment.
● Bulbs can be purchased from the SAMSUNG Service Centre.
Rear oven lamp
1. Remove cap by turning anticlockwise and remove the
metal ring, the sheet ring and clean the glass cap. If
necessary, replace the bulb with a 25 watt, 240 V, 300 °C
heat-resistant oven light bulb.
2. Clean the glass cap, the metal ring and the sheet ring if
necessary.
3. Fit the metal and the sheet ring to the glass cap.
4. Place glass cap where you have removed it in step 1 and
turn it clockwise to keep it in place.
��
��
��
